eCIR Exam - Guided By RedBlock

eCIR Field Guide (Full Edition) — Certified Incident Responder (eLearnSecurity / INE)

A comprehensive study, reference, and methodology pack for the eCIR exam — incident investigation, log analysis (Splunk & Elastic), PCAP/network-traffic analysis, endpoint & memory forensics, and a fully worked example.

Exam mindset: eCIR rewards the analyst mindset, not memorized syntax. For every suspicious artifact you find, the reflex is pivot and view it from every angle. Saw a PowerShell launch? Find its process-create event, its network connections, its registry writes, its child processes, its parent. Note everything — IPs, hashes, timestamps, usernames, filenames — because you will reuse them. The exam is two hands-on scenarios (Splunk, then Elastic + a PCAP): for each, reconstruct what happened, in what order, and which MITRE TTPs, then write it up as a timeline.

Table of Contents

1. Introduction to eCIR

2. Incident Response Mindset & Workflow

3. Log Sources & What They Tell You

4. Splunk SPL — Full Cheatsheet

5. Elastic / KQL — Full Cheatsheet

6. Windows Event Codes — Reference

7. Sysmon — Reference & Detections

8. PowerShell & Script-Based Attack Detection

9. Linux Incident Response

10. Web Attack Detection

11. Network & IDS Detection (Snort/Suricata/Zeek)

12. Wireshark / PCAP Investigation Methodology

13. Credential Access & Active Directory Attacks

14. Persistence Detection

15. Lateral Movement Detection

16. Command & Control / Exfiltration Detection

17. Endpoint & Memory Forensics (quick reference)

18. MITRE ATT&CK — Detection Mapping

19. Indicators of Compromise (IOC) Cheatsheet

20. Timeline Building & Report Template

21. Kerberos & Authentication Deep-Dive

22. Email / Phishing Analysis

23. Malware Triage Basics

24. Windows Disk Forensic Artifacts

25. Common Ports & Services Reference

26. Exam-Day Playbook

27. Glossary

28. Appendix A — Worked Example: Scenario 2 PCAP Report

29. Appendix B — Worked Example: Splunk Scenario (mini)

30. Appendix C — Quick "See X → Suspect Y" Table

1. Introduction to eCIR

The eCIR (eLearnSecurity Certified Incident Responder) tests the ability to investigate cyber incidents, analyze logs and network traffic, and think like a real SOC analyst — piecing together what happened during an attack and explaining it clearly, rather than reciting theory.

Study path & platforms

• HackTheBox (SOC Analyst Path) — learn how logs are correlated; strong for Splunk SPL practice.

• LetsDefend — sharpens the SOC-analyst mindset: judging whether an event is suspicious, what to pivot to next, and how to build a per-machine event timeline.

• Splunk Free — hands-on SPL.

• Elastic Stack on a VM — KQL in Discover; timeline building.

• Wireshark — PCAP analysis.

• Sysmon + Event Viewer — generating and reading Windows endpoint telemetry.

Exam format & advice

• Hands-on + report (an MCQ version has been announced — check the official INE site for the current format).

• Two scenarios: (1) Splunk, (2) Elastic with a PCAP to analyze. For each, reconstruct events into a timeline and map attacker techniques to MITRE ATT&CK TTPs.

• Don't over-invest in perfecting SPL or KQL syntax, or memorizing every Windows Event Code — understand them well enough to reason about what you find. Mindset over syntax.

• Note everything — a found attacker IP or initial-access point is a huge pivot you'll reuse repeatedly.

• Spot something suspicious → view it from all perspectives (network, registry, child processes, parent).

• Not easy, but very passable with good practice and an analyst mindset.

2. Incident Response Mindset & Workflow

The core loop (run this per finding):

1. Spot something suspicious (alert, odd process, weird connection).

2. Pivot — re-query the same event from other log sources / event types.

3. Expand — did it spawn children? Make network connections? Touch the registry? Drop files?

4. Anchor the artifacts (IP, host, user, PID, time) into your notes.

5. Chain — link this event to what came before and after.

6. Map to MITRE ATT&CK.

Note-taking template (keep open the whole exam):

[TIMESTAMP] HOST / USER
Source log      : (Splunk index / sourcetype / Sysmon EID / PCAP frame)
What happened   : one line
Key artifacts   : src.ip, dst.ip, hash, filename, PID, command line
MITRE           : Txxxx (Technique name)
Links to        : previous/next event

IR lifecycle (NIST SP 800-61 / SANS PICERL):

Attack-chain lens (order your findings this way): Initial Access → Execution → Persistence → Privilege Escalation → Defense Evasion → Credential Access → Discovery → Lateral Movement → Collection → Command & Control → Exfiltration → Impact.

Pyramid of Pain — detections built on TTPs (top) hurt attackers far more than hash/IP indicators (bottom): Hash → IP → Domain → Network/Host Artifact → Tool → TTP. Prioritize behavioral detections.

3. Log Sources & What They Tell You

4. Splunk SPL — Full Cheatsheet

Anatomy: index=<idx> sourcetype=<st> <filters> | <transform> | <stats/table/sort> — pipe passes results left→right; filter early, transform later.

Search & time

index=main sourcetype=WinEventLog:Security EventCode=4625     # failed logons
index=* "powershell" OR "cmd.exe"                             # free-text across all
index=main host=WIN-01 EventCode=4688 | head 50               # first 50 process creates
index=main earliest=-24h latest=now                           # relative time
index=main earliest="04/21/2019:16:00:00" latest="04/21/2019:18:00:00"   # absolute

Core commands (know these cold)

Detection query cookbook

# --- Brute force / password spray ---
index=main EventCode=4625 | stats count by src_ip, Account_Name | sort -count
index=main EventCode=4625 | stats dc(Account_Name) as accounts by src_ip | where accounts>10   # spray

# Failed-then-success from one source (successful brute)
index=main (EventCode=4625 OR EventCode=4624)
| stats count(eval(EventCode=4625)) as fails count(eval(EventCode=4624)) as success by src_ip, Account_Name
| where fails>10 AND success>0

# --- Execution ---
index=main (EventCode=4688 OR EventCode=1) | table _time host ParentImage Image CommandLine
index=main EventCode=1 ParentImage IN ("*winword.exe","*excel.exe","*outlook.exe","*w3wp.exe","*httpd*") Image IN ("*cmd.exe","*powershell.exe","*wscript.exe","*cscript.exe","*mshta.exe","*rundll32.exe","*regsvr32.exe")

# Encoded / download PowerShell
index=main (EventCode=4104 OR EventCode=1) (CommandLine="*-enc*" OR CommandLine="*FromBase64String*" OR CommandLine="*DownloadString*" OR CommandLine="*IEX*" OR CommandLine="*Invoke-Expression*")

# LOLBins
index=main EventCode=1 ((Image="*certutil.exe" AND CommandLine="*urlcache*") OR Image="*bitsadmin.exe" OR Image="*mshta.exe" OR (Image="*rundll32.exe" AND CommandLine="*javascript*"))

# --- Discovery ---
index=main EventCode=1 Image IN ("*whoami.exe","*net.exe","*net1.exe","*nltest.exe","*ipconfig.exe","*systeminfo.exe","*tasklist.exe","*arp.exe") | stats count by host, Image, CommandLine

# --- Credential access ---
index=main EventCode=10 TargetImage="*lsass.exe" | table _time host SourceImage GrantedAccess
index=main EventCode=1 (CommandLine="*comsvcs.dll*MiniDump*" OR CommandLine="*procdump*lsass*" OR CommandLine="*sekurlsa*" OR CommandLine="*mimikatz*")

# --- Persistence ---
index=main (EventCode=7045 OR EventCode=4697) | table _time host Service_Name Service_File_Name
index=main EventCode=4698 | table _time host Task_Name    # scheduled task
index=main EventCode=13 TargetObject="*\\CurrentVersion\\Run*"   # run key

# --- Lateral movement ---
index=main EventCode=4624 Logon_Type IN (3,9,10) | stats count by src_ip, Account_Name, Logon_Type
index=main EventCode=4624 Logon_Type=10 | table _time host src_ip Account_Name   # RDP

# --- C2 / network ---
index=main EventCode=3 | stats count by Image, DestinationIp, DestinationPort | sort -count
index=main EventCode=3 DestinationIp=<ip> | timechart span=1m count      # beaconing
index=main EventCode=22 | stats dc(QueryName) as uniq by host | sort -uniq   # DNS tunneling surface

# --- Anti-forensics ---
index=main EventCode=1102                # security log cleared
index=main EventCode=1 CommandLine="*wevtutil*cl*"

Tips: stats count by … | sort -count finds outliers fast; top/rare surface the single weird value; transaction/streamstats stitch a host's story; widen the time picker once you find an anchor; use lookup to tag known-bad IPs/hashes.

5. Elastic / KQL — Full Cheatsheet

Syntax: field: value and field2: "two words" and not field3: bad* and bytes >= 1000 — and/or/not, * wildcard, quotes for phrases, ranges with >= <= > <, parentheses to group.

Core ECS fields: host.hostname, event.code, event.action, event.outcome, data_stream.dataset, process.name, process.command_line, process.parent.name, process.entity_id, user.name, source.ip, destination.ip, destination.port, dns.question.name, url.original, http.request.method, winlog.event_data.*.

# Process create on a host
host.hostname: "WIN-01" and event.code: "1"

# Office/web spawning a shell
event.code: "1" and process.parent.name: ("winword.exe" or "excel.exe" or "outlook.exe" or "w3wp.exe") and process.name: ("cmd.exe" or "powershell.exe" or "mshta.exe" or "wscript.exe" or "rundll32.exe")

# Encoded PowerShell (script-block)
event.code: "4104" and powershell.file.script_block_text: (*FromBase64String* or *IEX* or *DownloadString* or *-enc* or *Invoke-Expression*)

# LOLBin download
process.name: "certutil.exe" and process.command_line: (*-urlcache* or *-decode*)

# LSASS access
event.code: "10" and winlog.event_data.TargetImage: *lsass.exe*

# Lateral movement logon types
event.code: "4624" and winlog.event_data.LogonType: ("3" or "9" or "10")

# New service
event.code: ("7045" or "4697")

# Scheduled task
event.code: "4698"

# Run-key persistence
event.code: "13" and registry.path: *\\CurrentVersion\\Run*

# DNS tunneling surface
event.code: "22" and dns.question.name: *

# Web attack in proxy/access logs
event.dataset: ("apache.access" or "nginx.access") and url.query: (*UNION* or *../* or */etc/passwd* or *<script* or *' or 1=1*)

Use Discover to filter, add columns, read raw winlog.event_data.*, then build a timeline by sorting on @timestamp. Save searches; use KQL + filter pills together.

6. Windows Event Codes — Reference

Security log (channel: Security)

Logon Types (4624 LogonType)

PowerShell channel

4104 script-block (deobfuscated code — read this) · 4103 module/pipeline · 400/403/600 engine start/stop.

7. Sysmon — Reference & Detections

Golden signals: parent-child anomalies (EID 1), LSASS access (EID 10), unusual outbound (EID 3), Run-key/registry persistence (EID 13), named pipes matching C2 defaults (EID 17/18).

8. PowerShell & Script-Based Attack Detection

Obfuscation indicators (4104): -enc/-EncodedCommand, FromBase64String, [char[]], backtick splitting, string reversal, -join, Invoke-Expression/IEX, DownloadString/DownloadFile, Net.WebClient, Reflection.Assembly, [Ref].Assembly.

AMSI / logging bypass (4104): amsiInitFailed, AmsiUtils, System.Management.Automation.AmsiUtils, VirtualProtect, EtwEventWrite patching.

index=main EventCode=4104 (Message="*amsiInitFailed*" OR Message="*AmsiUtils*" OR Message="*EtwEventWrite*" OR Message="*FromBase64String*" OR Message="*IEX*")

event.code: "4104" and powershell.file.script_block_text: (*AmsiUtils* or *amsiInitFailed* or *EtwEventWrite* or *VirtualProtect* or *FromBase64String*)

Tip: script-block logging (4104) records the deobfuscated code — even if the attacker sent base64, you often see the plaintext here.

9. Linux Incident Response

Sources: auditd (/var/log/audit/audit.log), /var/log/auth.log (Debian) / secure (RHEL), syslog, journald, ~/.bash_history, /var/log/cron.

# Reverse shell / suspicious exec
process.name: ("bash" or "sh" or "nc" or "ncat" or "python*" or "perl") and process.command_line: (*"-i"* or *"/dev/tcp/"* or *"-e /bin/"*)

# sudo to root by unexpected user
event.dataset: "system.auth" and process.name: "sudo" and message: *COMMAND=*

# Triage on a live/imaged host
last -f /var/log/wtmp                 # logins
grep -Ei "accepted|failed" /var/log/auth.log
ausearch -m execve --start recent     # recent process execs
cat /etc/passwd | awk -F: '$3<1000'   # system accounts / anomalies
crontab -l; ls -la /etc/cron.*        # persistence
find / -perm -4000 -type f 2>/dev/null # SUID hunt

10. Web Attack Detection

Work IIS/Apache/Nginx access logs (or apache.access/nginx.access datasets).

# SQL injection
index=web sourcetype=access_combined (uri_query="*UNION*" OR uri_query="*information_schema*" OR uri_query="*' OR 1=1*" OR uri_query="*sleep(*" OR uri_query="*waitfor delay*")

# LFI / path traversal
index=web (uri_query="*../*" OR uri_query="*..%2f*" OR uri_query="*/etc/passwd*" OR uri_query="*php://*")

# Command injection
index=web (uri_query="*;*" OR uri_query="*|*" OR uri_query="*`*" OR uri_query="*$(*" OR uri_query="*whoami*" OR uri_query="*nc *")

# Web shell = server process spawning a shell
index=main EventCode=1 ParentImage IN ("*w3wp.exe","*httpd*","*nginx*","*php-cgi*") Image IN ("*cmd.exe","*powershell.exe","*sh","*bash")

# Bursts of errors / scanning
index=web | stats count by status, src_ip | where status>=400

Signals: spikes of 4xx/5xx, abnormal response sizes, one IP hammering one parameter, odd user-agents (sqlmap, nikto, curl, empty), unexpected .php/.aspx/.jsp written to web root.

11. Network & IDS Detection (Snort / Suricata / Zeek)

• Snort/Suricata alerts land with tags: "snort.log" or event.dataset: suricata.eve. Pivot from rule.name/signature to host telemetry via source.ip/destination.ip.

tags: "snort.log" and network.type: "ipv4" and not destination.ip: 10.0.0.0/8

• Snort rule anatomy (read, don't necessarily write):

alert tcp any any -> $HOME_NET 445 (msg:"SMB exploit attempt"; content:"|FF|SMB"; sid:1000001; rev:1;)

• Zeek conn/dns/http/ssl logs give netflow-level pivoting when payloads aren't captured. conn.log (5-tuple + bytes), dns.log (queries), http.log (URIs/UAs), ssl.log (JA3/cert).

• Beaconing — regular-interval, similar-size connections to one destination (aggregate destination.ip + count + interval; watch for low jitter).

12. Wireshark / PCAP Investigation Methodology

Each step is a real tshark/capinfos command (parenthetical = what it reveals); tshark uses the same display filters as the Wireshark filter bar.

Step 0 — Facts about the capture

capinfos capture.pcap
# packet count, byte rate, FIRST/LAST packet time, SHA-256 (record the hash for the report)

Step 1 — What protocols exist? (scope)

tshark -r capture.pcap -q -z io,phs
# kerberos/ldap/smb/dcerpc = AD activity; irc/tftp/unusual high ports = follow up

Wireshark: Statistics → Protocol Hierarchy.

Step 2 — Who talks to whom? (actors)

tshark -r capture.pcap -q -z conv,ip     # top talkers by bytes
tshark -r capture.pcap -q -z conv,tcp    # per-flow breakdown
tshark -r capture.pcap -q -z endpoints,ip

Wireshark: Statistics → Conversations / Endpoints (sort by Bytes).

Step 3 — Resolve names & identities

tshark -r capture.pcap -Y "dhcp" -T fields -e ip.src -e dhcp.option.hostname
tshark -r capture.pcap -Y "kerberos" -T fields -e ip.src -e kerberos.realm -e kerberos.CNameString -e kerberos.SNameString
tshark -r capture.pcap -Y "ntlmssp.auth.username" -T fields -e ntlmssp.auth.domain -e ntlmssp.auth.username -e ntlmssp.auth.hostname

Step 4 — Authentication analysis

# Kerberos msg_type: 10 AS-REQ · 11 AS-REP · 12 TGS-REQ · 13 TGS-REP · 14 AP-REQ · 15 AP-REP · 30 KRB-ERROR
tshark -r capture.pcap -Y "kerberos.msg_type" -T fields -e frame.time -e ip.src -e ip.dst -e kerberos.msg_type -e kerberos.CNameString -e kerberos.etype
# etype 0x17/23 = RC4 (Kerberoast/downgrade); 0x12/18 = AES256

Step 5 — SMB (shares, files, lateral movement)

tshark -r capture.pcap -Y "smb2.tree" -T fields -e smb2.tree            # shares (IPC$, SysVol, custom)
tshark -r capture.pcap -Y "smb2.filename" -T fields -e frame.time -e smb2.filename

Step 6 — MS-RPC / DCERPC (enumeration & AD attacks)

tshark -r capture.pcap -Y "dcerpc.cn_bind_to_uuid" -T fields -e ip.src -e ip.dst -e dcerpc.cn_bind_to_uuid
tshark -r capture.pcap -Y "samr || drsuapi || srvsvc || lsarpc" -T fields -e frame.time -e ip.src -e dcerpc.opnum

Key UUIDs: DRSUAPI e3514235-4b06-11d1-ab04-00c04fc2dcd2 · SAMR 12345778-…-89ac · LSARPC 12345778-…-89ab · SRVSVC 4b324fc8-1670-01d3-1278-5a47bf6ee188 · Netlogon 12345678-…cffb. Watch: DRSUAPI opnum 3 = DsGetNCChanges = DCSync. (Opnum 0/1/12 = Bind/Unbind/CrackNames — not DCSync; verify before claiming replication.)

Step 7 — Web, DNS & C2 hunting

tshark -r capture.pcap -Y "http.request" -T fields -e http.host -e http.request.method -e http.request.uri -e http.user_agent
tshark -r capture.pcap -Y "dns.flags.response==0" -T fields -e dns.qry.name | sort | uniq -c | sort -rn
tshark -r capture.pcap -Y "tls.handshake.type==1" -T fields -e tls.handshake.extensions_server_name   # SNI for C2

Step 8 — Carve transferred files (prove what was taken)

tshark -r capture.pcap --export-objects "smb,./out_smb" -q
tshark -r capture.pcap --export-objects "http,./out_http" -q
grep -rl "cpassword" ./out_smb     # e.g. check GPP files for a recoverable password

Wireshark: File → Export Objects → SMB / HTTP; Follow → TCP/HTTP Stream to read full exchanges.

Handy Wireshark display filters

ip.addr==10.0.0.5 && tcp.port==445
http.request.method=="POST"
http.user_agent contains "powershell"
dns.qry.name contains "xxxx"          # long/odd subdomains
frame contains "password"             # cleartext creds
smb2.cmd==5                           # SMB2 Create (file access)
tcp.flags.syn==1 && tcp.flags.ack==0  # SYN scan
icmp.data.len > 48                    # ICMP tunneling

Triage principles

• Separate signal from noise — OCSP/CRL, Windows Update, SSDP, bulk LLMNR/NBNS are usually benign; document as excluded so they aren't mistaken for C2.

• Prove, don't assume — if an attack is plausible (e.g. DCSync), find the confirming packet or state it was checked and absent.

• Anchor every claim to a frame number and timestamp.

13. Credential Access & Active Directory Attacks

# Kerberoasting
event.code: "4769" and winlog.event_data.TicketEncryptionType: "0x17"
# AS-REP roasting
event.code: "4768" and winlog.event_data.PreAuthType: "0"
# DCSync from non-DC
event.code: "4662" and winlog.event_data.Properties: (*1131f6aa-9c07-11d1-f79f-00c04fc2dcd2* or *1131f6ad-9c07-11d1-f79f-00c04fc2dcd2*) and not user.name: *$

14. Persistence Detection

index=main (EventCode=7045 OR EventCode=4697 OR EventCode=4698)
| table _time host EventCode Service_Name Service_File_Name Task_Name

15. Lateral Movement Detection

event.code: "7045" and winlog.event_data.ServiceName: (*PSEXESVC* or *PAExec* or *RemCom*)
event.code: "1" and process.parent.name: ("wmiprvse.exe" or "wsmprovhost.exe") and process.name: ("cmd.exe" or "powershell.exe")
event.code: "4624" and winlog.event_data.LogonType: "10"

16. Command & Control / Exfiltration Detection

• Beaconing — regular interval + similar size to one dest; timechart span=1m (Splunk) or Sysmon 3 aggregation.

• DNS tunneling — high volume of TXT/NULL queries, long/high-entropy subdomains, many unique subdomains under one parent.

• HTTP(S) C2 — long-lived sessions, odd JA3, self-signed cert/odd SNI on 443, unexpected user-agent, no owning browser process.

• Ingress tool transfer — certutil/bitsadmin/curl/powershell DownloadString pulling payloads.

• Exfil — large outbound POST/PUT, big transfer to unknown IP, archive creation before upload.

# Possible exfil: large outbound
index=main EventCode=3 | stats sum(bytes_out) as out by host, DestinationIp | sort -out
# DNS tunneling surface
index=main EventCode=22 | stats dc(QueryName) as uniq by host | where uniq>200

17. Endpoint & Memory Forensics (quick reference)

Key Windows artifacts: Prefetch (C:\Windows\Prefetch, execution evidence), Amcache/Shimcache (program execution), $MFT (file timeline), Registry hives (SYSTEM/SOFTWARE/NTUSER — persistence, USB, run keys), Event logs (.evtx), Recycle Bin, Jump Lists, SRUM.

Volatility 3 quick commands (if a memory image is provided):

vol -f mem.raw windows.pslist          # processes
vol -f mem.raw windows.pstree          # parent-child tree
vol -f mem.raw windows.netscan         # network connections
vol -f mem.raw windows.cmdline         # process command lines
vol -f mem.raw windows.malfind         # injected code
vol -f mem.raw windows.dlllist --pid N # loaded DLLs
vol -f mem.raw windows.handles --pid N # handles

What to look for: unusual parent-child (e.g. services.exe→cmd.exe), processes with no disk path, injected regions (malfind), connections to odd IPs, lsass accessed by non-system processes.

18. MITRE ATT&CK — Detection Mapping

19. Indicators of Compromise (IOC) Cheatsheet

Track and pivot on these throughout an investigation:

• Network: attacker IPs, C2 domains, JA3 hashes, ports, user-agents.

• Host: file hashes (MD5/SHA1/SHA256), file paths, service/task names, registry keys, named pipes, mutexes.

• Account: compromised usernames, created accounts, privileged-group additions.

• Behavioral (highest value): parent-child chains, LOLBin usage, logon-type patterns, beacon intervals.

Keep a running IOC table; re-search each new IOC across all log sources and the full time range.

20. Timeline Building & Report Template

Timeline row format: time | host | user | action | evidence (source + ID/frame) | MITRE.

Report skeleton:

1. Executive Summary        (what happened, impact, severity — plain language)
2. Scope & Assets           (hosts, accounts, IPs involved)
3. Timeline of Events       (chronological, evidence-anchored)
4. Detailed Findings        (per finding: what, evidence, interpretation)
5. MITRE ATT&CK Mapping
6. Indicators of Compromise
7. Recommendations          (containment, eradication, hardening, detections)
8. Appendix                 (queries used, carved files, method)

Golden rule: every claim ties to evidence (event ID + timestamp, or frame number). If an attack is plausible but unproven, say it was checked and excluded.

21. Kerberos & Authentication Deep-Dive

Understanding the ticket flow makes Kerberos attacks obvious in logs/PCAP.

Normal flow:

1. AS-REQ / AS-REP (msg 10/11) — client proves identity to the KDC and receives a TGT (encrypted with the krbtgt key). Pre-authentication timestamp is encrypted with the user's password hash.

2. TGS-REQ / TGS-REP (msg 12/13) — client presents the TGT and requests a service ticket (TGS) for a specific SPN.

3. AP-REQ / AP-REP (msg 14/15) — client presents the service ticket to the target service.

• KRB-ERROR (msg 30) — errors, e.g. KRB5KDC_ERR_PREAUTH_REQUIRED (the expected first response before pre-auth).

Encryption types: 0x12 = AES256, 0x11 = AES128, 0x17 = RC4 (weak — downgrade/roasting signal), 0x03 = DES (legacy).

Attacks mapped to the flow:

Windows vs NTLM: NTLM (4776) is challenge-response and used for local/legacy/IP-based auth; Kerberos is used with hostnames in a domain. A sudden shift to NTLM or RC4 is worth a look (downgrade).

22. Email / Phishing Analysis

Header analysis (top to bottom = newest to oldest):

• Received: chain — trace the true origin (bottom-most external hop); mismatches with the claimed sender are suspicious.

• Return-Path / From / Reply-To mismatch — spoofing.

• SPF / DKIM / DMARC results (Authentication-Results) — fail/softfail = spoof risk.

• Message-ID domain not matching sender domain.

• Display-name spoofing (friendly name ≠ actual address).

Attachment / link triage:

• Hash the attachment → check reputation; detonate only in a sandbox.

• Office docs: look for macros (vbaProject.bin), external template injection, embedded objects.

• Archives hiding double extensions (invoice.pdf.exe), LNK files, ISO/IMG containers.

• URLs: decode redirects, check for look-alike/homoglyph domains, credential-harvest landing pages.

In logs: mail gateway logs (sender, subject, verdict), then pivot to endpoint — did the user open it? (Office→shell in Sysmon 1), did it beacon out (Sysmon 3)?

23. Malware Triage Basics

Static (no execution):

file suspicious.bin                 # type
sha256sum suspicious.bin            # hash → reputation lookup
strings -n 8 suspicious.bin | less  # URLs, IPs, commands, mutexes
# PE specifics: imports, sections, compile time, packer signatures (e.g. UPX)

Look for: embedded IPs/domains/URLs, suspicious API imports (VirtualAlloc, WriteProcessMemory, CreateRemoteThread), high-entropy sections (packing), unusual PE timestamps.

Dynamic (sandbox only): process tree, files dropped, registry changes, network callbacks, mutexes created. Map observed behavior to MITRE.

Golden rule: never run unknown samples outside an isolated VM/sandbox. For the exam you mostly observe artifacts of malware in logs rather than reverse it.

24. Windows Disk Forensic Artifacts

Timeline tip: combine $MFT, event logs, Prefetch, and registry timestamps into one super-timeline; anchor on the intrusion window.

25. Common Ports & Services Reference

26. Exam-Day Playbook

1. Read the scenario prompt — it hints at log sources and the questions asked.

2. Find an anchor — an alert, weird process, suspicious IP, failed-logon spike.

3. Pivot every artifact — one event → process-create, network, registry, children, parent.

4. Note relentlessly — IPs, hashes, filenames, PIDs, timestamps, users (reused later).

5. Widen the time window around each anchor.

6. Build the timeline in order; each row = time, host, user, action, evidence, MITRE ID.

7. Map TTPs as you go, not at the end.

8. Write the story — initial access → what they did → how it spread → impact.

Build the analyst reflex over perfect syntax: see something → view it from all angles → note it → chain it.

27. Glossary

• SPL — Search Processing Language (Splunk's query language).

• KQL — Kibana Query Language (Elastic's query language).

• ECS — Elastic Common Schema (normalized field names).

• Sysmon — System Monitor; Sysinternals tool producing rich endpoint telemetry.

• TTP — Tactics, Techniques & Procedures (attacker behavior).

• IOC — Indicator of Compromise.

• LOLBin — Living-Off-the-Land Binary (legit tool abused, e.g. certutil).

• TGT / TGS — Kerberos Ticket-Granting Ticket / Service Ticket.

• SPN — Service Principal Name (Kerberos service identifier).

• PtH / PtT — Pass-the-Hash / Pass-the-Ticket.

• DCSync — abusing replication (DsGetNCChanges) to pull password hashes.

• GPP — Group Policy Preferences (historically leaked cpassword).

• AMSI — Antimalware Scan Interface (often bypassed by script attacks).

• ETW — Event Tracing for Windows (telemetry source attackers tamper with).

• C2 — Command & Control.

• Beaconing — periodic C2 check-ins at regular intervals.

• JA3 — TLS client fingerprint.

• PICERL — SANS IR lifecycle (Prep, Identify, Contain, Eradicate, Recover, Lessons).

• MFT — Master File Table (NTFS file metadata / timeline).

• BYOVD — Bring Your Own Vulnerable Driver.

Appendix A — Worked Example: Scenario 2 PCAP Incident Report

Example / training material. A complete incident report produced from the lab capture scenario2-traffic-capture.pcap using the Section 12 methodology. Illustrative only — the environment is a training domain; the analysis demonstrates method and reporting style.

A1. Executive Summary

The capture records systematic Active Directory reconnaissance from a single internal host, HR1 (192.168.220.101), aimed at the domain controller W2012r2-DC01 (192.168.220.11) and, later, a second workstation (192.168.220.102). Over ~100 minutes HR1 authenticated to the DC on a ~5-minute cadence and enumerated across Kerberos, LDAP/CLDAP, SMB/SMB2 and MS-RPC (SAMR, DRSUAPI, LSARPC, SRVSVC, Netlogon), using identities vulnscan (Kerberos), luser (NTLM), HR1$ (machine) and an anonymous NULL SMB session. The cadence and the account name vulnscan fit an authenticated vulnerability scan / AD assessment tool; regardless of intent the behavior matches an adversary's discovery phase.

Verified by file carving: the GPP ScheduledTasks.xml files read from SysVol contain no cpassword — they deploy the environment's own Sysmon and Autoruns as SYSTEM; secret.txt was never read (listed only). Ruled out: no DCSync (DRSUAPI did only Bind/DsCrackNames, no DsGetNCChanges); external web traffic (OCSP/CRL/Windows Update/SSDP) is benign, not C2.

A2. Assets & Identities

Identities from HR1: TESTDOMAIN\vulnscan (Kerberos, ~5-min cadence) · TESTDOMAIN\luser (NTLM) · TESTDOMAIN\HR1$ · NULL/anonymous.

A3. Timeline of Events (UTC)

A4. Detailed Findings

A4.1 Repeated credentialed Kerberos auth (vulnscan). TGT requests every ~5 min; fixed cadence + account name indicate an automated authenticated scan. Etypes AES256 (0x12) and RC4 (0x17) offered.

A4.2 AD object enumeration via LDAP + DRSUAPI DsCrackNames. HR1 binds DRSUAPI and issues DsCrackNames (opnum 12) alongside CLDAP/LDAP. No DsGetNCChanges (opnum 3) — this is not DCSync.

A4.3 SysVol / GPP reads — technique exercised, no credential exposed. HR1 pulls ScheduledTasks.xml from two GPOs plus audit.csv. Both XML files were carved and contain no cpassword; they define legitimate SYSTEM tasks deploying Autoruns (\\192.168.220.11\Share\autoruns\install.bat) and Sysmon (\\192.168.220.11\share\sysmon\sysmon.bat). Classic GPP credential-hunt (MS14-025) that returned nothing; also discloses the defensive posture.

A4.4 Access to a share with security tooling and secret.txt. HR1 browses \\192.168.220.11\share (contents: autoruns, filebeat, sysmon, secret.txt) and downloads the Sysmon config and binary. Carving confirms secret.txt was never transferred — filename disclosed only, no exfiltration.

A4.5 Domain Admins enumeration via SAMR — privilege recon. SamrConnect5 → OpenDomain → LookupNames("Domain Admins") → OpenGroup → GetMembersInGroup. Maps who holds Domain Admin.

A4.6 Lateral reconnaissance to 192.168.220.102. SRVSVC share enumeration, repeated — discovery extended beyond the DC.

A4.7 Anonymous (NULL) SMB session. NULL logon from HR1 alongside authenticated ones — consistent with anonymous enumeration.

A4.8 Benign / noise (excluded). External HTTP = OCSP/CRL/Windows Update via Microsoft-CryptoAPI; SSDP M-SEARCH (Chrome); high-volume LLMNR/NBNS = normal name resolution. Repeated wpad queries seen but no malicious responder answered (no poisoning).

A5. MITRE ATT&CK Mapping

Not observed: T1003.006 (DCSync) — explicitly checked and absent.

A6. Recommendations

1. Identify the process/tool on HR1 driving vulnscan; if sanctioned scanning, document/exempt, else isolate and treat as compromised.

2. The two GPP files here contain no cpassword (verified) — no rotation needed from them; as hygiene, sweep all domain GPP files for cpassword.

3. Remove secret.txt and sensitive material from \\192.168.220.11\share; restrict ACLs (not exfiltrated here, but filename disclosed).

4. Disable anonymous/NULL SMB; enforce SMB signing.

5. Alert on SAMR/LSARPC privileged-group enumeration (4662 / SACLs on Domain Admins).

6. Alert on bulk SysVol GPP reads (ScheduledTasks.xml/Groups.xml).

7. Disable WPAD/LLMNR/NBT-NS to close the poisoning surface.

8. Baseline vulnscan; page on cadence/target deviation.

A7. Carved File Evidence

Interpretation: the GPP/SysVol artifacts are the environment's own monitoring deployment (Sysmon + Autoruns via SYSTEM scheduled tasks). HR1 downloaded the Sysmon config and binary — the clearest data-access event, useful for evasion planning — but obtained no credentials and did not read secret.txt.

Appendix B — Worked Example: Splunk Scenario (mini)

Example / training material. An illustrative walkthrough of how you'd work a Splunk scenario end-to-end. Field names are generic — adapt to the actual index/sourcetypes on the exam.

Prompt (typical): "A workstation is suspected compromised via a phishing email. Determine initial access, what executed, and whether the attacker moved laterally."

Step 1 — Establish the window & host. Start broad, find the anchor.

index=* host=WKSTN-07 | stats count by sourcetype   # what telemetry exists
index=main host=WKSTN-07 EventCode=1 | timechart span=1h count   # activity spikes

Step 2 — Initial access: Office spawning a shell.

index=main host=WKSTN-07 EventCode=1 ParentImage IN ("*winword.exe","*excel.exe","*outlook.exe")
| table _time ParentImage Image CommandLine

Found: winword.exe → powershell.exe -enc <base64> at 09:14 → T1566 / T1059.001. Note the time as the anchor.

Step 3 — Deobfuscate & find the payload pull.

index=main host=WKSTN-07 EventCode=4104 | table _time Message   # script-block shows plaintext
index=main host=WKSTN-07 EventCode=3 Image="*powershell.exe"     # where did it call out?

Found: PowerShell DownloadString from http://185.x.x.x/a.ps1, then a Sysmon 3 connection to that IP → T1105 (Ingress Tool Transfer). Record the C2 IP as an IOC.

Step 4 — Persistence check.

index=main host=WKSTN-07 (EventCode=13 TargetObject="*\\Run*") OR EventCode=7045 OR EventCode=4698

Found: Run-key added pointing to the dropped payload → T1547.001.

Step 5 — Credential access.

index=main host=WKSTN-07 EventCode=10 TargetImage="*lsass.exe"

Found: powershell.exe accessing lsass → T1003.001. Attacker likely has creds now — pivot on any new accounts used.

Step 6 — Lateral movement.

index=main EventCode=4624 Logon_Type IN (3,10) Account_Name=<compromised_user>
| stats count by ComputerName, src_ip, Logon_Type

Found: type 3 logons from WKSTN-07 to SRV-DB01 → T1021. Scope now includes a second host.

Step 7 — Build the timeline & write it up.

09:14  WKSTN-07  jdoe   winword.exe → powershell -enc         Sysmon 1 / 4104   T1566, T1059.001
09:14  WKSTN-07  jdoe   PS DownloadString 185.x.x.x/a.ps1     Sysmon 3          T1105
09:15  WKSTN-07  jdoe   Run-key persistence                   Sysmon 13         T1547.001
09:16  WKSTN-07  jdoe   lsass access (cred dump)              Sysmon 10         T1003.001
09:22  SRV-DB01  jdoe   network logon from WKSTN-07           4624 type 3       T1021

Lesson: each finding fed the next pivot. That chain — not any single query — is the answer.

Appendix C — Quick "See X → Suspect Y"

End of guide. All queries and filters are templates — validate against the actual data set before relying on them. Appendix A is illustrative training material.
